Banana Pi BPI-M2M (A33) - A33 quad-core single board computer, without eMMC

Banana Pi BPI-M2 Magic (BPi-M2M) is an efficient quad-core solution designed for Internet of Things applications. It uses an Allwinner R16 chip design, which outperforms competitors in terms of system performance, scalability, and energy efficiency. It can be used for home entertainment, home automation, and high wireless performance.

BPI-M2 Magic integrates four ARM Cortex-A7 CPU cores and Mali400MP2 graphics architecture. It also includes a variety of peripherals, featuring 512MB DDR3 RAM, 4 lane MIPI DSI, LVDS, USB 2.0 OTG/Host, 802.11 b/g/n Wi-Fi, and Bluetooth 4.0.

BPI-M2 Magic can run smoothly with Android as well as Debian, Ubuntu Linux, Raspberry Pi images, and other operating systems. It can easily run games as it supports 1080P high-definition video output. The GPIO is compatible with Raspberry Pi and can run Raspberry Pi images directly.

Note: Banana Pi BPI-M2 Magic does not have an HDMI interface nor does it support an RJ45 interface.

Specifications:

• SoC: Allwinner A33, quad-core ARM Cortex-A7 at 1.5 GHz, also supports R16 design
• GPU: Mali 400 MP2
• SDRAM: 512 MB DDR3 (shared with GPU)
• Power: 5 V at 2 A via DC power
• Low-level peripherals: 40-pin header, 28 GPIO, some of which can be used for specific functions including UART, I2C, SPI, PWM
• Wi-Fi: Wi-Fi 802.11 b/g/n 2.4 GHz
• Bluetooth: BT 4.0 BLE
• Onboard storage: MicroSD (TF) card
• Display: MIPI Display Serial Interface (DSI) interface (4 data lanes)
• Camera: A CSI input connector. Supports 8-bit YUV422 CMOS sensor interface, supports CCIR656 protocol for NTSC and PAL, supports 5M pixel camera sensor, supports video capture solution up to 1080p at 30 fps
• Video decoder: Multi-format FHD video decoding, including MPEG1/2, MPEG4, H.263, H.264, etc. H.264 high-profile 1080p at 60 fps
• Video encoder: H.264 encoder, high profile 1080p at 60 fps
• Audio input: onboard.
