Siemens Logo 230RCE

Logo! 230RCE, logic module, display SVEA: 115V 230V relay, DE4 DA, SP. 400 blocks, modularly expandable, Ethernet, integrated web server, data logging, custom web pages, standard microSD card for Logo! Soft Comfort from V8.4, older projects executable, cloud connectivity, MQTT in all Logo! 8.4 basic devices. The Logo! basic devices with digital inputs and outputs and their compact installation width of 72 mm integrate many well-known functions such as pulse relays, stairwell timers, auxiliary relays, time relays, etc., which can be combined in various ways. Switching programs can be easily created and simulated on a PC. The integrated Ethernet interface allows communication with up to nine Logo! modules or SIMATIC S7 systems. With the also integrated web server, connected consumers can be monitored and controlled via WLAN or the Internet. Users can design the web pages themselves, even without HTML knowledge. Additional modules enable GSM or GPS communication as well as integration into a KNX building management system. Logo! basic devices are available with and without displays for various input voltages and with transistor or relay outputs up to 10 rated current. Expandable with additional modules to up to 24 DI, 20 DQ, 8 AI, 8 AQ. Integrated cloud communication. Logo! can also be expanded with an external text display for clear text messages. The background color is selectable for visual highlights. Various Logo! power modules for power supply are also available.
