Siemens 7KM3220-0BA01-1DA0

SENTRON PAC3220 LCD 96x96 mm Power Monitoring Device is a panel-mounted device for measuring electrical quantities. Protocol: Modbus TCP. With a graphical display. Rated voltage: 690/400V, 45-65Hz. Rated current: X/1A or X/5A AC. Auxiliary power: 100 - 250 V ±10 % AC/DC. Screw terminal connection.

The multifunction measuring device SENTRON 7KM PAC3220 accurately captures all important electrical measurements in energy distributions to assess system conditions and power quality in the process and manufacturing industries, as well as in critical infrastructures such as hospitals and data centers. It provides comprehensive information about your electrical installation and energy distribution, along with important metrics for evaluating system status.

Thanks to various communication options, the devices can be easily integrated into higher-level automation and energy management systems via Modbus TCP, PROFINET, PROFIBUS, and Modbus RTU. With additional modules, further digital inputs and outputs, analog inputs, neutral conductor direct measurement, or residual current measurement can be implemented. The 7KM PAC measuring devices are available in various versions to suit your needs. SENTRON PAC - specialists in measurement data acquisition.
