Siemens 3RF2450-1AB35

Siemens Digital Industry Semiconductor Relay 2RF2, 3 3RF2450-1AB35

Manufacturer: Siemens Digital Industry
Designation: Semiconductor Relay 2RF2, 3-phase AC51 50A 48-600V
Type: 3RF2450-1AB35
Rated control supply voltage Us at AC 50 Hz: 90..125 V
Rated control supply voltage Us at AC 60 Hz: 90..125 V
Voltage type for actuation: AC
Operating voltage: 48 V
Rated operational current Ie at AC-1: 50 A
Rated operational current Ie at AC-51: 50 A
Number of phases: 3
Suitable for rail mounting: yes

Further details:
3-phase semiconductor relay 3RF2 AC 51 / 50 A / 40 °C 48-600 V / 110 V AC 2-phase controlled screw connection with a blocking voltage of 1200 V. SIRIUS 3RF24 semiconductor relay for switching resistive/inductive loads, such as heaters or valves in a filling plant. The devices switch wear-free and silently, making them ideal for noise-sensitive areas (offices, hospitals). They are also extremely reliable at high switching frequencies. With the heat sink already integrated, they can be directly installed in the control cabinet. The compact design saves space on the DIN rail. The semiconductor relays can also be easily expanded for various applications using the standardized function modules 3RF29 by simply clicking them on. The devices are globally certified (e.g., IEC and UL/CSA). The semiconductor relays are available as single-phase or three-phase devices. They come in various power ratings and rated operating voltages. Designed for AC or DC actuation, they are available with screw, spring-loaded, or ring terminal connections. Accessories include not only function modules 3RF29 but also control plugs and terminal covers. Simple, efficient, always up-to-date - the SIRIUS system modular concept. EAN: 4011209777521.
