Shuttle Barebone XPC nano NC10U5

Intel Core i7-8565U
Ratings
Currently out of stock
Free shipping starting at 50.–

Product details

The Shuttle XPC nano NC10U5 is a compact barebone mini-PC designed for versatile applications. Equipped with an Intel Core i7-8565U processor, it delivers high performance for demanding tasks. The mini-PC supports up to 32 GB of DDR4 RAM and allows for the installation of HDDs or SSDs via a 2.5-inch bay as well as an M.2 slot. With integrated Intel UHD Graphics 620, it is capable of displaying high-resolution content. Connectivity is ensured through multiple ports such as HDMI, DisplayPort, and USB 3.2, while network connectivity is provided via Gigabit LAN and Wi-Fi standards like 802.11b/g/n. The Shuttle XPC nano NC10U5 is designed for 24/7 operation, making it ideal for use in business environments or as a media center.

  • Supports up to 32 GB of DDR4 RAM for high performance
  • Integrated Intel UHD Graphics 620 for impressive graphics display
  • Versatile connectivity options, including HDMI and DisplayPort
  • Suitable for 24/7 operation, ideal for business applications
  • Compact design for space-saving installations.

Key specifications

Number of processor cores
4 -Core
Graphics card model
UHD Graphics 620
Internal connection options
S-ATA III (1x)
Network connections
RJ45 (1x)
Video connections
HDMI (1x)
Memory type
DDR4-RAM
USB ports
USB-A
Item number
12534910

General information

Manufacturer
Shuttle
Category
Barebones
Manufacturer no.
NC10U7 BLACK
Release date
16.1.2020

Barebone properties

Design
All-in-one

Processor

Processor type
Intel Core i7-8565U
Clock frequency
1.80 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Number of threads
8
Socket
BGA 1528
Max. turbo clock rate
4.60 GHz
Max. TDP
15 W

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Number of pins
2 x
Memory Slots available
2
Max. memory slots
2
Max. RAM
32 GB
Memory voltage
1.20 V

Graphics card properties

Graphics card model
UHD Graphics 620
Max. connected monitors
2 x

Internal connections

Internal connection options
S-ATA III (1x)
Data storage controller
Intel SoC
"Number of 5.25"" drive slots"
1 x
Number of 3.5" drive slots (internal)
1 x
Number of 3.5" drive slots (external)
1 x
"Number of 2.5"" drive slots"
1 x

External connections

USB ports
USB-A
Exact USB ports
USB-A 2.0 (2x)
Data ports
PS/2 (2x)

Network

Network connections
RJ45 (1x)
Max. port speed
150 Mbit/s

Wireless transmission

Connectivity
Ethernet
Wi-Fi standard
Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n

Video connections

Video connections
HDMI (1x)

Card reader properties

Memory card type
SD, SDHC, SDXC

Power supply properties

Power
65 W

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Barebone PC

Product dimensions

Weight
400 g
Width
142 mm
Length
1420 mm
Height
420 mm

Package dimensions

Length
25.70 cm
Width
24.40 cm
Height
14 cm
Weight
1.44 kg
