Shuttle Barebone XPC AIO P52U Intel Celeron 5205U 39.62cm 15.6inch 2xSODIMM DDR4 1xM.2 1xSATA 1xHDMI
Intel Celeron 5205UOnly 2 items in stock at supplier
Product details
XPC All-in-One P52U
15.6" All-in-One PC for POS, POI, and Kiosk Applications
The Shuttle All-in-One PC product family now includes models in three screen sizes: 11.6", 15.6", and 19.5". The P52U model series features a capacitive 15.6" multi-touchscreen with Full HD resolution. An Intel Ultra-Low-Voltage (ULV) processor ensures high computing power with low energy consumption. Thanks to completely passive cooling, the system operates virtually silently, is maintenance-free, and is suitable for 24/7 continuous operation. The arrangement of most ports on the underside of the case and the front's resistance to dust and splashes according to protection class IP54 also make it ideal for applications in vertical markets.
Specifications
Fanless and Quiet
- Passive heat pipe cooling, no fan noise
- Ideal for noise-sensitive environments
- Reduced dust contamination - making it virtually maintenance-free
24/7 Continuous Operation
This device is officially approved for 24-hour continuous operation (24/7).
Requirements:
- Free air circulation around the PC
- Accessible ventilation holes on the device.
- If a hard drive is installed, it must also be approved by the manufacturer for 24/7 operation.
IP54 Protection Class
- The device front is protected against dust and splashes according to protection class IP54.
Case
- Color: Black
- Dimensions: 393.6 x 272.5 x 39.8 mm (WxHxD)
- 100 mm VESA mount
- Mounting hole for Kensington Lock
- Weight: 3.25 kg net, 4.5 kg gross
Operating System
- This system is delivered without an operating system.
It is compatible with:
- Windows 11 - 64-Bit
- Windows 10 - 64-Bit
- Linux - 64-Bit
Touchscreen
- Screen with touch functionality for finger input
- Capacitive touchscreen with 10-point multitouch support
- Supports operation with PVC, cotton, linen gloves - max. 0.4 mm thick.
Number of processor cores | 2 -Core |
Graphics card model | Intel UHD Graphics |
Internal connection options | M.2 PCIe (1x) |
Network connections | RJ45 (1x) |
Video connections | HDMI (1x) |
Memory type | DDR4-RAM |
USB ports | USB-A |
Item number | 22753631 |
Design | All-in-one |
Processor type | Intel Celeron 5205U |
Clock frequency | 1.90 GHz |
Number of processors | 1 x |
Number of processor cores | 2 -Core |
Number of threads | 2 |
Socket | FCBGA1528 |
Max. turbo clock rate | 1.90 GHz |
Max. TDP | 65 W |
Processor properties | Intel vPro |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Memory Slots available | 2 |
Max. memory slots | 2 |
Max. RAM | 64 GB |
Memory voltage | 1.20 V |
Graphics card model | Intel UHD Graphics |
Max. connected monitors | 2 x |
Internal connection options | M.2 PCIe (1x) |
Data storage controller | Intel SoC |
"Number of 2.5"" drive slots" | 1 x |
USB ports | USB-A |
Exact USB ports | USB-A 3.2 Gen 1 (4x) |
Data ports | PS/2 (2x) |
Network connections | RJ45 (1x) |
Connectivity | Ethernet |
Video connections | HDMI (1x) |
Audio outputs | Headphones Out (1x) |
Memory card type | SD, SDHC, SDXC |
Power | 65 W |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 2 x 2.5" HDD mounts |
Weight | 3250 g |
Width | 393.60 mm |
Length | 39.80 mm |
Height | 272.50 mm |
Length | 46 cm |
Width | 13 cm |
Height | 43 cm |
Weight | 4.58 kg |
