Shanling EH3

USB-DAC, USB host, Display, gain switch, Bluetooth, Wi-Fi
Delivered between Mon, 5.5. and Tue, 6.5.
Only 1 item in stock at supplier

Exact colour description

Product details

The Shanling EH3 Desktop DAC/AMP is an impressive combination of advanced technology and flexibility, packaged in an attractive design. At its core is the 8-channel ESS ES9039SPRO D/A converter, renowned for its excellent sound reproduction with outstanding clarity and precision. This exceptional performance is supported by fully balanced amplification with four OPA1612 chips and a dual power supply system that minimizes interference in both the digital and analog domains. The EH3 stands out with its remarkable ability to effortlessly drive a wide range of headphones, regardless of their impedance. With a power output of up to 19 W at 32 Ohms in unbalanced mode and up to 53 W at 32 Ohms in balanced mode, it demonstrates its power and versatility. The EH3 features advanced connectivity options such as Bluetooth 5.0 and WiFi (2.4G/5G). With its numerous ports (4 headphone jacks, USB, optical, coaxial, I2S HDMI, XLR, RCA), it is a versatile addition to any audio setup. Technical specifications such as a channel separation of 110 dB, a signal-to-noise ratio of 124 dB at 32 Ohms, and an output impedance of 2 Ohms confirm the high quality and performance of the EH3. Operation is straightforward thanks to an intuitive user interface with a multifunctional knob for volume control and navigation, complemented by the ability to be remotely controlled via the included remote control as well as an app for smartphones and tablets. The Shanling EH3 is a prime example of the successful fusion of powerful audio technology, diverse connectivity options, and thoughtful design, making it a top choice for audiophiles and music lovers seeking a premium desktop DAC/AMP.

Key specifications

Headphone amplifier application area
GamingHiFiPCStudio
Wireless transmission
BluetoothWi-Fi
Power supply
Electrical connection
Item number
44747421

General information

Manufacturer
Shanling
Category
Headphone amplifiers
Manufacturer no.
EH3 black
Release date
25.7.2024
Sales rank in Category Headphone amplifiers
38 of 291

Colour

Colour
Black
Exact colour description
Black

Headphone amplifier properties

Headphone amplifier application area
GamingHiFiPCStudio
Headphone Amplifier Features
Displaygain switchUSB hostUSB-DAC
Wireless transmission
BluetoothWi-Fi

Audio properties

Frequency range
20 - 40000 Hz
Recommended headphone impedance
8 - 600 Ω (ohm)
Output Impedance
2 Ω (ohm)
signal-to-noise ratio
124 dB
distortion factor
0 %
Sample rate
768 kHz
Audio resolution
32 bits

Connections

Data ports
RS-232 (2x)
Audio inputs
Digital in
Audio outputs
Headphone jack 3.5mm (1x)Headphone jack 6.3mm (1x)XLR (1x)

Power supply

Power supply
Electrical connection

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
1x operating instructions1x power cable1x remote1x Shanling EH3

Product dimensions

Length
188 mm
Width
255 mm
Height
68 mm
Weight
2400 g

Package dimensions

Length
37.90 cm
Width
33.20 cm
Height
14.30 cm
Weight
3.89 kg
