Seeed Studio OV5647 62 FOV camera for Raspberry Pi 3B+4B

Experience high-quality surveillance and large-area recordings with the OV5647 camera module. This module is specially designed for the Raspberry Pi 3B and 4B and offers a wide field of view of 62 degrees thanks to its fisheye lens. With a resolution of 2592 x 1944 pixels and an adjustable focus of 3.4 mm, the camera is perfect for landscape photography and security surveillance. The camera is easy to mount as it has four screw holes that allow for stable mounting. This versatile camera is ideal for use in large spaces and for detailed image recording.

Recommended accessories:
Grove Vision AI Module V2

Features:
The camera uses a 5 megapixel OV5647 sensor for razor-sharp images. With an active image size of 2592 x 1944 pixels, the camera offers a high resolution. The fisheye lens enables a wide field of view of 62 degrees for comprehensive images. The module supports the Raspberry Pi 3B, 3B+ and 4. Thanks to the four screw holes on the module, the camera is easy to attach. The adjustable focal length of 3.4 mm enables flexible focus settings.

Application examples:
Surveillance of large landscapes or gardens. Security surveillance in large rooms or halls. High-quality image recordings for scientific projects. Live streaming of events or presentations. Large-scale nature and wildlife photography.

Technical data:
Manufacturer: Seeed Studio
Manufacturer SKU: 114110127
Sensor: OV5647
CMOS size: 1/4 inch
Resolution: 5 megapixels (2592 x 1944 pixels)
Video resolution: 1080p@30fps, 720p@60fps
FOV: 62 degrees
Pixel size: 1.4 µm x 1.4 µm
Focal length: 3.4 mm (adjustable)
F-Stop: 2.8
Supported hardware: Raspberry Pi 3B, 3B+, 4
Power supply: 3.3 V (pin 15)
Operating temperature: -20°C to 70°C
Dimension: 25 x 25 x 9 mm
Weight: 11g

Scope of delivery:
1x OV5647 62 FOV camera for Raspberry Pi 3B+4B
1x 15-pin FFC connection cable.
