Schneider Electric TM5SE2IC01024

This product is part of the Modicon TM5 series, a range of modules for modular IP20 I/O systems. The counting module offers 2 inputs, 16/32-bit counting resolution with sinking (positive) discrete logic. It is a counting module with a discrete input voltage of 24 V DC and a maximum power dissipation of 1.51 W. Additionally, it has an input/output current consumption of 63 mA at 24 V DC, a auxiliary input of 2 x 24 V DC, and an encoder power supply of 24 V DC. This product is part of a flexible and scalable I/O configuration for automation solutions. The maximum cycle time is 2 ms, and the resolution of the counting inputs is 16bit/32bit. The product complies with protection class IP20 and weighs 0.025 kg. The Modicon TM5 meets the typical requirements of production and packaging machines, as well as material handling and assembly systems. This product is certified by CE, C-Tick, CSA, GOST-R, and CULus. It complies with the standards IEC 61131-2, UL 508, CSA C22.2 No 213, and CSA C22.2 No 142. This product is compatible with the Modicon LMC058 motion controller and the Modicon M258 logic controller. This modular IP20 I/O system offers a flexible and scalable configuration of extensions and distributed I/O islands. This is made possible by connecting to Modicon controllers (TM5 bus) or via CANopen bus/Sercos bus for Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
