Schneider Electric Motor protection relay 18A

Ratings
BrandMore from Schneider Electric
Delivered between Tue, 8.7. and Thu, 10.7.
Only 1 item in stock at supplier
Free shipping starting at 50.–

Product details

FLC motor rating: 12 to 18 A
Rated contact current: 18 A
Contact configuration: 3P
Series: TeSys
Rated contact voltage: 690 V AC
Mounting type: Direct contactor
Series: LRD2
Contact configuration: Normally open/normally closed contact
Number of auxiliary contacts: 2
Reset type: Automatic, manual
Width: 45 mm
Operating temperature range: -20 to +60 °C

This is a three-pole thermal overload relay designed to protect AC circuits from overload, phase failure, long start times, and permanently blocked motors. It features a setting dial for adjustable relays, a test button, a stop button, manual/automatic reset, and a trip indicator. The cover is designed for sealing and includes a normally closed/normally open contact as an auxiliary contact. It can be mounted directly under three-pole contactors or independently on DIN rails. The insulation voltage is 600 V, with a dielectric strength of 6 kV.

Key specifications

input voltage
690 V
Scope of delivery
Motor protection relay 12.00-18.00A
Output voltage
690 V
Electric current output
12 A
Relay type
Overload relay
Item number
9726796

General information

Manufacturer
Schneider Electric
Category
Relays
Manufacturer no.
LRD21
Release date
24.9.2018
External links
Manufacturer's site (de)

Relay properties

Relay type
Overload relay
input voltage
690 V
Output voltage
690 V
Electric current output
12 A
Manufacturer Type
Lrd21

Smart home features

Smart Home
Not compatible

Origin

Country of origin
China

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Schneider Electric fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Motor protection relay 12.00-18.00A

Product dimensions

Length
90 mm
Width
45 mm
Height
48 mm

Package dimensions

Length
8.50 cm
Width
7.40 cm
Height
9.60 cm
Weight
145 g
