Schneider Electric LSSwitch C20H

Ratings
BrandMore from Schneider Electric
Delivered between 3.3.2026 and 17.3.2026
free shipping

Product details

The C20H circuit breaker from Schneider Electric is a highly advanced protective switch specifically designed for use in electrical installations. With a rated current of 100 A and a D-characteristic, this switch provides reliable protection against short circuits and overloads. The thermomagnetic release unit ensures precise and rapid response to electrical disturbances. The switch is suitable for mounting on DIN rails and features a compact design that allows for high packing density in the control cabinet. The iDPN circuit breaker complies with the IEC/EN 60898-1 standards and can be combined with various auxiliary modules that offer additional functions such as fault tripping and undervoltage protection. With an operating voltage of up to 400 V AC and an insulation voltage of 440 V AC, the C20H is suitable for a wide range of applications in electrical installation.

  • Thermomagnetic release unit for precise protection
  • Compatible with RCD blocks and auxiliary modules
  • High packing density due to compact design
  • Complies with IEC/EN 60898-1 standards
  • Suitable for mounting on DIN rails.

Key specifications

Circuit breaker type
Miniature circuit breaker
Mounting type
Top-hat rail
Width
27 mm
Length
73 mm
number of poles
1
Item number
12899235

General information

Manufacturer
Schneider Electric
Category
Residual-current device
Manufacturer no.
A9N18447
Release date
12.3.2020
External links
Manufacturer's site (de)

Colour

Colour
White
Exact colour description
White

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
Mounting type
Top-hat rail
number of poles
1
Tripping characteristic
C
Rated current
100 A
Rated voltage
415 V
voltage type
AC
Rated insulation voltage Ui
500 V
Protection type (IP code)
IP20

Origin

Country of origin
France

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Schneider Electric fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
73 mm
Width
27 mm
Height
81 mm
Weight
125 g
