Purecrea 8-Channel Logic Level Converter TXS0108E
More than 10 pieces in stock at third-party supplier
Product details
With this module, you can connect controllers with different logic voltages. For example, the Raspberry Pi operates at 3.3V while the Arduino Uno runs at 5V. If you want to connect these devices via SPI, you can use this converter module. The board features 8 channels and can be easily used on breadboards. It works with all protocols (SPI, serial, I2C) and digital signals. Analog signals are not supported by this board.
Technical details:
Chip: TXS0108E
Maximum baud rate: 110 Mbps
Supply voltage VA: 1.2V to 3.6V
Supply voltage VB: 1.65V to 5.5V
Dimensions: 26 x 16 x 3 mm
Weight: 3.5 g
Included in delivery:
1x 8-channel Logic Level Converter TXS0108E
1x Pin header set.
Item number | 37686569 |
Manufacturer | Purecrea |
Category | Development boards + Kits |
Release date | 23.8.2023 |
Sales rank in Category Development boards + Kits | 276 of 2696 |
Operating voltage | 3.60 V |
Analogue outputs | 8 |
Max. port speed | 110 Mbit/s |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Scope of delivery | 1x 8-channel logic level converter TXS0108E, 1x pin header set |
Weight | 3.50 g |
