ProfiCNC Hex Aero HERE 3

The Here 3 is the new version of the very popular Here 2 GNSS module. Like its predecessor, it features a powerful STM32F302 Cortex-M4 MCU. The positioning accuracy has been further improved and can now be determined with centimeter precision. Additionally, the design has been revised, resulting in better visibility of the LEDs and enhanced water and dust resistance.

Technical Specifications

• Processor: STM32F302
• Positioning Accuracy: 3D: 2.5 m / RTK: 0.025 m
• IMU Sensor: ICM20948
• Protocol Communication: CAN
• Operating Temperature: -40 °C to 85 °C
• Dimensions: 76 mm x 76 mm x 16.6 mm
• Weight: 48.8 g

Included in the Package

• Here 3.
