Range: PNOZmulti 2
Series: PNOZ m ES
Type: Communication module
For use with: PNOZmulti 2
Supply voltage: 24 V DC
Fieldbus communication type: Profinet
Connection type: Screw terminal
Display included: Yes
Mounting type: DIN top-hat rail
Dimensions: 101.4 x 22.5 x 110.4 mm
CE, cULus approval, TÜV, BG, CCC. Screw terminals. The PNOZmulti 2 communication/fieldbus module Profinet allows for connection to a base unit from the configurable PNOZmulti 2 control system. It can be configured using the PNOZmulti Configurator. Connections for Profinet status, diagnostics, and error displays facilitate communication with Profinet. In the PNOZmulti Configurator, 128 virtual inputs and outputs can be defined on the PNOZmulti 2 control system. Transmission speed is 100 Mbit/s (100BaseTX), supporting full and half duplex. A maximum of one PNOZ m ES Profinet can be connected to the base unit. It features two RJ45 connections and operates as a Profinet I/O device (V2.2) in accordance with conformance class C. Supported functions include RT, IRT, MRP, LLDP, and I;M 0-4.
input voltage | 24 V |
Item number | 11815845 |
Manufacturer | Pilz |
Category | Relays |
Manufacturer no. | 772138 |
Release date | 30.8.2019 |
External links |
input voltage | 24 V |
Manufacturer Type | PNOZ m ES Profinet |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Width | 22.50 mm |
Height | 101.40 mm |
Weight | 86 g |
