Panasonic Industrial relay CB 1 NO contact DC 12V 40A PCB pins

Minimum order 5
Ratings
BrandMore from Panasonic
Delivered between Thu, 31.7. and Mon, 18.8.
More than 10 pieces in stock at third-party supplier
Supplied by
Free shipping starting at 50.–

Product details

The Panasonic CB 1 Normally Open Industrial Relay is a reliable and powerful component designed for various industrial applications. With a coil voltage of 12 V DC and a maximum switching current of 40 A, this relay offers high efficiency and stability. Its compact design allows for easy integration into existing systems, while the through-hole mounting ensures a secure and durable installation. The relay is equipped with printed pins that facilitate easy connection and handling. The use of silver alloys in the contact material enhances conductivity and longevity, making it an ideal choice for demanding applications.

  • Maximum switching current of 40 A for high power requirements
  • Through-hole mounting for easy installation and integration
  • Contact material made of silver alloy for improved conductivity
  • Suitable for DC applications with a coil voltage of 12 V.

Key specifications

input voltage
12 V
Output voltage
12 V
Output current type
DC
Electric current output
40 A
Relay type
Step switch
Item number
52639215

General information

Manufacturer
Panasonic
Category
Relays
Manufacturer no.
CB1A-P-12V
Release date
5.11.2024
Minimum order
5
Minimum order
5

Relay properties

Relay type
Step switch
input voltage
12 V
Output voltage
12 V
Electric current output
40 A
Output current type
DC
Number of closers
1 x
Number of poles
1 x

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Panasonic fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Product dimensions

Length
26 mm
Width
22 mm
Height
25 mm
