Moxa PTC-101-S-LC-LV - Industrial 10/100BaseT(X) to 100BaseFX media converter

Industrial 10/100BaseT(X) to 100BaseFX media converter, singlemode with LC connector, two redundant power inputs (20 to 70 VDC), -40 to 85°C Operating temperature

Ethernet interface
10/100BaseT(X) ports (RJ45 connector)

• 1

100BaseFX ports (singlemode LC connector)

• 1

Magnetic isolation protection

• 1.5 kV (built-in)

Performance parameters
Input voltage

• 20 to 72 VDC

Input current

• 150 mA @ 20 VDC

Overload current protection

• Supported

Current consumption

• 150 mA @ 20 VDC

Physical characteristics
Housing

• Metal

Dimensions

• 152.15 x 126.46 x 66.65 mm (5.99 x 4.86 x 2.62 in)

Weight

• packed: 952 g (2.09 lb)
• product only: 785 g (1.73 lb)

Installation

• DIN rail mounting

Environmental conditions
Operating temperature

• 40 to 85°C (-40 to 185°F)

Storage temperature (including packaging)

• 40 to 85°C (-40 to 185°F)

Relative humidity
5 to 95% (non-condensing)

Standards and certifications
EMC

• EN 55032/35

EMI

• CISPR 32, FCC Part 15B Class A

EMS

• IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
• IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
• IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV
• IEC 61000-4-5 Surge: Power: 4 kV; Signal: 4 kV
• IEC 61000-4-6 CS: 150 kHz to 80 MHz: 10 V/m; Signal: 10 V/m
• IEC 61000-4-8 PFMF
• IEC 61000-4-11

Environmental testing

• IEC 60068-2-1
• IEC 60068-2-14
• IEC 60068-2-2
• IEC 60068-2-3

Safety

• EN 62368-1, UL 62368-1, UL 60950-1

Vibration

• IEC 60068-2-6

Power Substation

• IEC 61850-3

MTBF
Time

• 4.660,534 hours

Standards

• Telcordia SR332.
