The square Intel NUC is a powerful mini-PC with approximately 10 centimeters on each side, designed for entertainment, gaming, and productivity. Its customizable motherboard allows for the memory, storage, and operating system configuration you desire.
The Intel NUC is an energy-efficient, fully functional PC that not only meets your performance requirements but also fits in the palm of your hand.
It's time for a new device. If you want to experience Windows 10 in all its variety, treat yourself to a new device with an Intel Core processor. Get top-notch performance for lightning-fast system startups, effortless web browsing, smooth app switching, and fluid multitasking, along with great battery life.
Home Entertainment - The perfect home theater PC. Opt for a compact 10 cm home entertainment system. With the new NUC featuring a standard HDMI port and a mini DisplayPort, you can enjoy images in 4K resolution with unprecedented brilliance.
Personal Hub. Use an Intel NUC system as an affordable, space-saving media library with cutting-edge entertainment components and features.
Number of processor cores | 2 -Core |
Graphics card model | Iris Plus Graphics 650 |
Internal connection options | M.2 (1x), S-ATA III (2x) |
Network connections | RJ45 (1x) |
Video connections | HDMI (1x), Thunderbolt (1x) |
Memory type | DDR4-RAM |
USB ports | Thunderbolt 3, USB-A |
Item number | 6072020 |
Manufacturer | Intel |
Category | Barebones |
Manufacturer no. | BOXNUC7I7BNH |
Release date | 9.5.2017 |
Design | Small Form |
Processor type | Intel Core i7-7567U |
Clock frequency | 3.50 GHz |
Number of processors | 1 x |
Number of processor cores | 2 -Core |
Number of threads | 4 |
Socket | BGA 1356 |
Max. turbo clock rate | 4 GHz |
Max. TDP | 28 W |
Processor properties | 64-bit architecture, Direct I/O Virtualization Technology (VT-d), Intel Virtualisation Technology (VT-x) |
Memory type | DDR4-RAM |
Memory form factor | SO-DIMM |
Number of pins | 260 x |
Memory chip compatibility | DDR4-2133 |
Memory Slots available | 2 |
Max. memory slots | 2 |
Max. RAM | 32 GB |
Memory voltage | 1.20 V |
Graphics card model | Iris Plus Graphics 650 |
Hardware application range | Beginner |
Max. connected monitors | 3 x |
Internal connection options | M.2 (1x), S-ATA III (2x) |
Data storage controller | Intel onboard |
RAID configuration | 0, 1 |
"Number of 2.5"" drive slots" | 1 x |
USB ports | Thunderbolt 3, USB-A |
Exact USB ports | Thunderbolt 3 (1x), USB-A 3.0 (4x) |
Network connections | RJ45 (1x) |
Max. port speed | 1000 Mbit/s |
Connectivity | Bluetooth, WLAN |
Wi-Fi standard | Wi-Fi 5 / 802.11ac |
Wi-fi frequency | 5 GHz |
Bluetooth version | 4.2 |
Video connections | HDMI (1x), Thunderbolt (1x) |
Audio outputs | Headphones Out (1x) |
Memory card type | microSDXC |
Power | 65 W |
Manufacturer commitment | RE100 |
Manufacturer compensation | According to RE100, the manufacturer Intel fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Scope of delivery | External power supply, Manual, VESA kit |
Width | 115 mm |
Length | 111 mm |
Height | 51 mm |
Length | 14 cm |
Width | 13 cm |
Height | 12 cm |
Weight | 1.17 kg |
How often does a product of this brand in the «Barebones» category have a defect within the first 24 months?
Source: Digitec GalaxusHow many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?
Source: Digitec GalaxusHow often is a product of this brand in the «Barebones» category returned?
Source: Digitec Galaxus
Bei Rechen- und 3D-Performance liefert der NUC7I7BNH nur geringe Vorteile im Vergleich zu deutlich billigeren Verwandten mit Core i5-7000 oder sogar Core i3-7000. Er macht sich auch akustisch stärker bemerkbar. Attraktiv ist der Core-i7-NUC vor allem, wenn man USB 3.1 beziehungsweise Thunderbolt 3 nutzen möchte.
