Intel Arc B-Series graphics for desktops are engineered from the ground up to deliver immersive gameplay, fast content creation, and easy-to-use AI capabilities.
Length | 27.20 cm |
Number of shaders | 2560 x |
Graphics card model | Arc B580 |
Video memory clock | 19 GHz |
Max. connected monitors | 4 x |
Max. Video resolution | 7680 x 4320 pixels |
Power consumption | 190 W |
Item number | 53601821 |
Manufacturer | Intel |
Category | Graphics card |
Manufacturer no. | 31P06HB0BA |
Release date | 13.12.2024 |
Sales rank in Category Graphics card | 118 of 1217 |
Max. connected monitors | 4 x |
PCI Express version | PCIe 4.0 |
Max. Video resolution | 7680 x 4320 pixels |
Expansion card form factor | 2 slots |
LED colour | without LED |
Graphics chip (GPU) | Intel Arc Graphics |
Graphics card model | Arc B580 |
Clock frequency | 1700 MHz |
Boost frequency | 2670 MHz |
Number of shaders | 2560 x |
Video memory type | GDDR6 |
Storage capacity | 12 GB |
Video memory clock | 19 GHz |
Memory Interface | 192 bits |
Memory Bandwidth | 456 GB/s |
Graphics card cooling system | Active cooler |
Number of fans | 2 x |
DirectX version | 12 |
OpenGL version | 4.60 |
Video connections | DisplayPort (3x), HDMI (1x) |
HDMI version | 2.1 |
DisplayPort version | 2.1 |
Power consumption | 190 W |
Min. recommended system performance | 600 W |
Power connectors | 8-pin PCI-E |
Country of origin | China |
Manufacturer commitment | RE100 |
Manufacturer compensation | According to RE100, the manufacturer Intel fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Length | 27.20 cm |
Width | 11.50 cm |
Height | 11.50 cm |
Length | 40.60 cm |
Width | 20.60 cm |
Height | 10.10 cm |
Weight | 1.82 kg |
How often does a product of this brand in the «Graphics card» category have a defect within the first 24 months?
Source: Digitec GalaxusHow many working days on average does it take to process a warranty claim from when it arrives at the service centre until it’s back with the customer?
Source: Digitec GalaxusHow often is a product of this brand in the «Graphics card» category returned?
Source: Digitec Galaxus
Intel is far from the top of the fastest graphics cards. But Intel hasn't promised a real top model either. When tested, the Arc B580 was about as fast as Nvidia's Geforce RTX 4060 - with the same disadvantage: the performance is not sufficient for gaming in 4K resolution, but customers in this price range can't expect that either...
Intel is far from the top of the fastest graphics cards. Intel has not promised a top model either. When tested, the Arc B580 was as fast as Nvidia's older RTX 4060, with the same disadvantage: the performance is not sufficient for 4K gaming, which is not to be expected from cards in this price range.
