ifm Electronic level sensor

Ifm Electronic Sensor LMACE-A12E-QSKG-2/US

Manufacturer: Ifm Electronic
Designation: Sensor
Type: LMACE-A12E-QSKG-2/US
Sensor Length: 113 mm
Sensor Diameter: 30 mm
Suitable for Safety Functions: no
Switch Function Type: Changeover
Switch Output Type: PNP/NPN
Electrical Connection Type: M12 Connector
Number of Semiconductor Outputs with Signaling Function: 1
Actuation Type: Other
Interface Type: PROFIBUS
Interface Type for Safety-Related Communication: none
Housing Design: Smooth Cylinder
Housing Coating: Other
Cascadable: no
Max. Output Current at Safe Output: 100 mA
Supply Voltage: 18..30 V
Rated Control Supply Voltage Us at DC: 18..30 V
Voltage Type: DC
With Monitoring Function for Connected Devices: no
Housing Material: Metal
Explosion Protection Category for Gas: none
Explosion Protection Category for Dust: none

Ifm Electronic Sensor LMACE-A12E-QSKG-2/US: Additional Details
Level Sensors, Electronic Level Sensor, Process Connection: G ¿ A, 4-Wire, DC PNP/NPN, Operating Voltage: 18...30 V DC, Current Consumption: 50 mA, 2 x Normally Closed / Normally Open Programmable, 2 x n.o. / n.c. programmable Connector, M12 Connector, Gold-Plated Contacts, Probe Length: 11 mm, Communication Interface: IO-Link 1.1, Housing Material: 1.4404 (V4A / 316L) PEEK PEI FKM, Materials in Contact with Medium: PEEK, Surface Finish: Ra < 0.8, EAN: 4021179266802.
