HellermannTyton Cable ties

HellermannTyton Cable Tie T50LDH-HS-BK-C1

Manufacturer: HellermannTyton
Description: Cable Tie
Dimensions: 385 x 4.7 mm
Type: T50LDH-HS-BK-C1
Width of the strap: 4.7 mm
Strap length: 395 mm
Strap thickness: 1.4 mm
Max. bundle diameter: 100 mm
Min. bundle diameter: 1.6 mm
Min. holding force: 225 N
Operating temperature: -40 to 125 °C
Design: internally toothed
Strap closure: plastic tongue/nose
Material: plastic
Material quality: polyamide (PA)
Surface protection: untreated
UV-stable according to ASTM D6779: no
Halogen-free: yes
Color: black
Transparent: no
Fluorescent: no
Labeling area: none
Removable closure: no
Mounting type: none
VG approval: no
MIL approval: no
UL approval: yes
Flammability class of the insulating material according to UL 94: V2

Additional details:
Parallel guiding of two bundles with just one cable tie. Cable tie with double closure head. Bundling with one internally and one externally toothed loop. Different materials are available. Bundles can have different diameters. The maximum bundle diameter is understood as the maximum combined bundle diameter. Simple manual processing is possible. For increased process reliability, cable tie tools are available. Double closure heads are ideal for the parallel guiding of two cable bundles. The need for a second, additional cable tie is eliminated. From the automotive industry to construction vehicles and white goods, the DH series is found in a variety of applications. It is also a practical helper in the packaging industry. The first loop closes and secures a bag, while the second loop is transformed into a carrying handle.
