Hager MCS125. Rated current: 25 A. Type: C-type, Module quantity (max): 1 module(s). Width: 17.5 mm

was CHF16.70
Ratings
Delivered between Thu, 10.7. and Sat, 19.7.
More than 10 pieces in stock at supplier
Free shipping starting at 50.–

Product details

Hager Circuit Breaker MCS125

Manufacturer: Hager
Designation: Circuit Breaker 1p. C-25A 6kA 1M QC
Type: MCS125
Installation Depth: 70 mm
Tripping Characteristic: C
Number of Poles (total): 1
Number of Protected Poles: 1
Rated Current: 25 A
Rated Voltage: 400 V
Rated Insulation Voltage Ui: 500 V
Rated Impulse Voltage Uimp: 4 kV
Rated Switching Capacity Icn according to EN 60898 at 230 V: 6 kA
Type of Voltage: AC
Rated Switching Capacity Icu according to IEC 60947-2 at 230 V: 10 kA
Frequency: 50..60 Hz
Energy Limitation Class: 3
Flush Mounting: yes
Switching Neutral Conductor: no
Overvoltage Category: 3
Pollution Degree: 2
Additional Devices Possible: no
Width in Division Units: 1
Protection Class (IP): IP20
Ambient Temperature During Operation: -25..70 °C
Connectable Wire Cross-Section Multi-stranded: 1..25 mm²
Connectable Wire Cross-Section Single-stranded: 1..35 mm²
Explosion Protected: no

Hager Circuit Breaker MCS125: Additional Details
Single-pole circuit breaker 6kA C-characteristic 25A QuickConnect 1 module. Circuit breaker with QuickConnect terminal according to DIN EN 60898-1 (VDE 0641 Part 11), outgoing up to 16A and incoming for distribution up to 63A, with delayed thermal tripping for overload protection and electromagnetic tripping for short-circuit protection. Suitable for retrofitting additional devices. Labeling option directly on the device and individual removal from the phase rail connection by unlocking the DIN rail quick fastening.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
70 mm
Width
17.50 mm
mounting style
Built-in
number of poles
1
Item number
20762450

General information

Manufacturer
Hager
Category
Residual-current device
Manufacturer no.
MCS125
Release date
4.5.2022

Colour

Colour
Grey
Exact colour description
Grey/white

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Built-in
number of poles
1
Tripping characteristic
C
Rated current
25 A
Rated voltage
400 V
voltage type
AC
Rated insulation voltage Ui
500 V
Protection type (IP code)
IP20

Origin

Country of origin
France

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
17.50 mm
Height
83.40 mm
