Hager HHA160H

Hager Circuit Breaker HHA160H

Manufacturer: Hager
Designation: Circuit Breaker X160 3P 25kA 160A
Type: HHA160H
Rated Continuous Current Iu: 160 A
Rated Voltage: 220..415 V
Rated Short-Circuit Breaking Capacity Icu at 400 V, 50 Hz: 25 kA
Overload Release Current Setting: 100..160 A
Setting Range of the Short-Time Delay Short-Circuit Release: 0 A
Setting Range of the Instantaneous Short-Circuit Release: 1600 A
Integrated Earth Fault Protection: no
Connection Type for Main Circuit: Screw Connection
Device Design: Built-in Device Fixed Installation Technology
Suitable for DIN Rail Mounting: yes
DIN Rail Mounting Optional: no
With Trip Indicator: yes
With Integrated Under-Voltage Release: no
Number of Poles: 3
Position of Connection for Main Circuit: Front
Design of the Operating Element: Knob
Complete Device with Protection Unit: yes
Integrated Motor Drive: no
Optional Motor Drive: no
Protection Class (IP): IP40

Hager Circuit Breaker HHA160H: Additional Details
Circuit breaker h3 x160 TM ADJ 3P3D 160A 25kA CTC. Circuit breaker according to DIN EN 60947-2 size x160, with thermal (adjustable) and magnetic (fixed) tripping for the protection of electrical installations and networks. Mounting on DIN rail or mounting plate. The position of the knob indicates the three different operating states (ON = top, OFF = bottom, tripped = middle position). Frame terminals for Cu cables are included as standard. The switches feature a mechanical test button. The functionality of the circuit breakers can be expanded with various accessories.
