Gelid Termopady Ultimate 120x20x3.0mm TP-GP04-R-E
3 mm8 pieces in stock at supplier
Product details
Thermopad Gelid GP-Extreme 120x20x3mm TP-GP05-E
Main Features:
- High flexibility
- Easy installation
The Gelid GP-Extreme thermal pad is a thermally conductive pad used wherever a flexible material with high thermal conductivity is required, such as: connectors, water blocks, power components, SMD elements, etc. Due to its soft structure, it is excellent for cooling irregularly shaped components and elements placed at different heights. It allows for filling gaps from microscopic scratches to visible irregular surfaces. Thanks to its excellent thermal conductivity, the pads can also be used for large components such as bridges on a motherboard, hard drives, densely packed elements on a circuit board, etc.
Main Advantages:
- High thermal conductivity of 12 W/mK – leading in its class.
- Easy to apply.
- It does not conduct electricity.
- Rust-free, non-hardened, non-toxic.
Hardness (Shore): 35 OO
Product Specifications:
- Color: Gray
- Thermal conductivity: 12 W/mK
- Density: 2.8 g/cm3
- Dimensions: 120 x 20 mm
- Thickness: 3 mm
- Manufacturer: Gelid
- Warranty: 24 months
It is not recommended to use a thermal pad that is compressed to more than half of its nominal thickness.
Length | 20 mm |
Width | 120 mm |
Thickness | 3 mm |
Density | 3.20 g/cm³ |
Max. temperature | 200 °C |
Item number | 34368001 |
Manufacturer | Gelid |
Category | Thermal pads |
Manufacturer no. | TP-GP04-R-E |
Release date | 17.5.2023 |
Colour | Grey |
Thermal paste type | Heat conducting pad |
Max. temperature | 200 °C |
Density | 3.20 g/cm³ |
Items per sales unit | 1 x |
CO₂-Emission | |
Climate contribution |
Length | 20 mm |
Width | 120 mm |
Thickness | 3 mm |
Length | 15.60 cm |
Width | 6.50 cm |
Height | 0.60 cm |
Weight | 38 g |
