Eaton Foot-operated coarse hand switch FAK-S/KC11/I

Foot Large Push Button 230 V/AC 6 A

The typical buzzer as a complete device.

Technical specifications:

• Connection (components): Screws
• Type of illumination: None
• Installation diameter: 9 mm
• Color of housing/button: Black, Light Grey (RAL 7035)
• Functions (switch/button): momentary
• Quantity: 1 pc.
• Contact type (LOV): 1 Normally Closed, 1 Normally Open
• Product dimensions, height: 101 mm
• Product dimensions, Ø: 94 mm
• Switch/Button type (categorization): Foot Large Push Button
• Switch/Button features: Raised actuator
• Switching voltage: 230 V/AC
• Switching position: 1 x Off/(On)
• Maximum switching current: 6 A
• Protection class: IP67
• Type (manufacturer type): FAK-S/KC11/I

Note: In the description of the switching position, the values in parentheses indicate that it is a momentary function.
