EAO Full face grn illum plugin swit,24V,IP67
Delivered between Wed, 27.5. and Mon, 1.6.
More than 10 pieces in stock at third-party supplier
More than 10 pieces in stock at third-party supplier
Supplied by
Distrelec CH
Free shipping starting at 50.–
Colour2
Product details
Switching sequence: Pushbutton end
Contact arrangement: 1-pole on/off switch
Mounting type: Front panel mounting
Panel cutout size: 22.5mm
Rated contact current: 200 mA @ 42 VDC
Illuminated: Yes
Actuator color: Green
Connection type: Solder/quick connect
This is a full-surface, flush illuminated switch. This selection of illuminated pushbutton switches offers full-face, very bright LED illumination. These illuminated switches are low-profile for flush mounting and provide a high level of environmental protection. Features and benefits include:
- IP rating: IP67
- Contact rating: 200 mA @ 42 V ac/dc (Max. power 2 W)
- Flat switch, only 2 mm high
- Mounting depth behind panel: 31mm
- LED voltage: 24 V dc
- N/O contact with gold-plated contacts.
Colour | Green |
Width | 86 mm |
Diameter | 22.50 mm |
Item number | 10099164 |
Manufacturer | EAO |
Category | Buttons + Switches |
Manufacturer No. | EUK-535-0625.0001 |
Release date | 13.11.2018 |
Colour | Green |
Exact colour description | Green |
Material group | Plastic |
LED lighting | Green |
Number of poles | 1x |
Nominal voltage | 24 V |
Nominal current | 0.20 A |
Protection type (IP code) | IP67 |
Switch + push-button Additional function | Lighting |
CO₂ emissions | 95.84 kg |
Climate contribution | CHF 2.28 |
Length | 117 mm |
Width | 86 mm |
Height | 28 mm |
Diameter | 22.50 mm |
