MegaRAID 9540-8i
Ensure data protection for performance-hungry applications with PCIe Gen 4.0 host and storage interfaces.
The MegaRAID 9500 series is the industry's first PCIe Gen 4.0 RAID adapter family, offering PCIe Gen 4.0 host and storage interfaces. The MegaRAID 9540-8i adapter, based on the SAS3808 PCIe 4.0 x8 IO controller, delivers double the performance of previous generations.
Small and medium-sized enterprises (SMEs) using entry-level server platforms and workstations require cost-effective, reliable storage solutions. The MegaRAID 9540-8i Tri-Mode Storage Adapter is a PCIe Gen 4.0 12 Gb/s SAS/SATA/PCIe (NVMe) controller card that meets these needs by providing proven performance and RAID data protection for a range of critical applications.
The adapter's Tri-Mode SerDes technology seamlessly bridges speeds and protocols, enabling the operation of NVMe, SAS, or SATA devices in a single drive bay, thereby maximizing performance and flexibility from each drive protocol.
Internal connection options | mini-SAS (1x), SAS (8x) |
Expansion slot | PCI Express x8 (1x) |
Number of connectable hard disks | 240 x |
RAID configuration | 0, 1, 10, JBOD |
Controller type | RAID controller |
Item number | 23982707 |
Manufacturer | Broadcom |
Category | Storage controller |
Manufacturer no. | 05-50134-03 |
Release date | 30.8.2023 |
Controller type | RAID controller |
Expansion card form factor | Full Profile, Low profile |
Number of ports | 8 ports |
Number of connectable hard disks | 240 x |
RAID configuration | 0, 1, 10, JBOD |
Storage Controller Additional Functions | Hot swapping |
Expansion slot | PCI Express x8 (1x) |
Internal connection options | mini-SAS (1x), SAS (8x) |
Scope of delivery | 1 piece |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 150 mm |
Width | 30 mm |
Weight | 325 g |
Length | 23.40 cm |
Width | 15 cm |
Height | 5.60 cm |
Weight | 257 g |
