BOFA Solder fume extraction kit System V250, with 6-stage speed control

Extraction system for series production with two extraction arms to filter large air volumes. The device features a multi-stage HEPA filter and a filter status indicator. It is suitable for protecting two users who can work either side by side or opposite each other. The device was primarily designed for the extraction of smoke generated during manual soldering in electronics manufacturing. This portable system is offered complete with point extraction and an installation kit that includes all necessary accessories for the hassle-free setup of a workstation.

Version with speed control: Extraction with two surface extraction points and a wired remote control. This allows for turning the device on and off, adjusting the power (6 levels), as well as monitoring the filter status.

Features:

• for two workstations
• unique, removable seal on the mounting plate
• easy and quick to assemble
• table mount with socket function
• granulated activated carbon filter
• filter saturation indicator
• powder-coated housing

Delivery includes:
1 piece of extraction unit V250
1 piece of combined HEPA/gas filter
1 piece of pre-filter mat
2 pieces of ESD extraction arm, Ø50 mm, length 900 mm with angled nozzle
2 pieces of extraction hose 2.5 m
2 sets of table mounting kit
1 piece of remote control (only with 801107)
1 piece of power cable

Selection criteria:
Version: with 6-stage speed control

Technical data:
Power: 135 W
Dimensions L x W x H: 260 x 260 x 380 mm
Flow rate: 180 m³/h
Hose diameter: 50 mm
Hose length: 2.5 m
Noise level: <55 dB(A)
Filter efficiency: 99.997 %
Weight: 0 g

Article number: BOFSYS250-SCB.
