Product details
The ASUS Crosshair V Formula-Z is a powerful motherboard designed specifically for gamers and overclocking enthusiasts. Equipped with the AMD 990FX/SB950 chipset, it offers a variety of features that ensure optimal performance and user experience. Support for Windows® 8 and the integration of ROG-specific features make it an ideal choice for modern gaming demands. With SupremeFX III audio technology and GameFirst II for ultra-fast LAN, both sound and network speed are elevated to a new level. The motherboard allows for easy customization and tuning through features like ROG Connect and USB BIOS Flashback. Additionally, it provides high flexibility in the use of RAM and other components, making it a future-proof solution for demanding users.
- Support for up to 32 GB of DDR3 RAM with a maximum clock speed of 2400 MHz
- Integrated 7.1-channel audio output for an immersive sound experience
- Enhanced security features with TPM header for improved data encryption
- Multi-GPU support for NVIDIA Quad-SLI and AMD 3-Way CrossFireX
- Quick access to BIOS and optimized boot options for Windows 8.
Processor family | Phenom II |
Memory type | DDR3-RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | S-ATA III (8x) |
Mainboard features | Front panel audio connector |
Item number | 374081 |
Manufacturer | ASUS |
Category | Motherboards |
Manufacturer no. | 90-MIBJ70-G0EAY0VZ |
Release date | 13.11.2012 |
External links |
Form factor | ATX |
Socket | AM3+ |
Chipset | AMD 990FX |
Mainboard features | Front panel audio connector |
BIOS type | UEFI |
Processor family | Phenom II |
Memory form factor | DIMM |
Number of pins | 240 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 32 GB |
Memory chip | DDR3-1066 (PC3-8500), DDR3-1333 (PC3-10666), DDR3-1600 (PC3-12800) |
Max. RAM OC | 2400 MHz |
Supported memory speed | 1600 MHz, 2133 MHz, 2400 MHz |
Memory type | DDR3-RAM |
RAM buffer | Unbuffered |
Multi-GPU technology | AMD 3-Way CrossFireX, NVIDIA Quad SLI, NVIDIA SLI |
Network connections | RJ45 Gigabit Ethernet (1x) |
Ethernet controller brand | Intel |
Max. port speed | 1 Gbit/s |
Chip | SupremeFX |
Audio channel | 7.1 Channel |
Audio Connections | Audio In |
Internal connection options | S-ATA III (8x) |
Expansion slot | PCI Express x2 (1x) |
PCI express version (max.) | 2 |
Number of fan connector | 8 |
Power connectors | 24-pin ATX, 4-pin Molex, 8-pin ATX 12V |
CO₂-Emission | |
Climate contribution |
Scope of delivery | S-ATA cable, User manual |
Length | 305 mm |
Width | 244 mm |
Height | 244 mm |
