Arcol HS100 wirewound resistor,100R 100W

Resistance: 100Ω
Power: 100W
Series: HS100
Package Type: Aluminum Housing
Tolerance: ±5%
Technology: Wire-wound
Connection Type: Axial
Maximum Temperature Coefficient: -100ppm/°C
Maximum Temperature Coefficient: +100ppm/°C
Temperature Coefficient: ±100ppm/°C
Dimensions: 24.1 x 88 x 47.5 mm

To achieve the specified maximum rated power of this power resistor, it is designed to be mounted directly on a suitable heat sink with thermal connection. This wire-wound power resistor in an aluminum housing is rated for 100W and belongs to the HS series. These resistors are manufactured in accordance with the requirements of MIL 18546, IEC 115, and RoHS. The high-power resistors of the HS series in aluminum packaging offer an unmatched balance between pulse current capability and compact size. The advanced design optimizes stability, linearity, and reliability, making the HS series resistors suitable for many applications.

Features:

• Compact size for rated power
• Winding design maximizes pulse load capacity
• Excellent load resistance

Applications:

• Brake resistor
• Inrush current limiter
• Inverter/Converter
• Clamp diode
• Balancing resistor.
