Product details

The REC-BL25A offers an adjustable BEC voltage range from 6V to 7.4V, with a factory standard of 5.5V. The BEC output utilizes a switch-mode power supply suitable for 11.1V to 22.2V (3S to 6S) LiPo batteries, providing a continuous current of 3A and a peak current of 7A. It features three programmable throttle curve settings for quick throttle response and a governor mode for speed control.

The small and compact PCB design allows for easy installation, while the large heatsink ensures excellent thermal performance. It is highly compatible and works with 98% of brushless motors on the market. The ultra-smooth motor start design is suitable for all types of brushless motors.

The power connection is equipped with a "Low ESR" capacitor made in Japan to ensure stable power supply. The throttle stick offers over 200 steps of resolution for improved throttle response and control. Users can adjust the motor settings via the transmitter using a super-stylized CPU.

In the event of an unexpected landing or crash, the aircraft locating option can be activated by turning off the transmitter. If the ESC does not receive a signal from the transmitter for 30 seconds, an alarm will sound to help the pilot locate the aircraft. Please note that this option is not compatible with PCM receivers that have the SAVE function activated or with low-noise PM receivers.

Key specifications

Engine type
Accessories and spare parts

General information

Item number
12649360
Manufacturer
Align
Category
RC motors
Manufacturer No.
HES02501T
Release date
5.2.2020

Engine properties

Engine type
Accessories and spare parts
RC Electric motor type
Brushless electric motor
Power consumption
25 A

Speed controller features

Speed controller type
Brushless
usableness
Aeroplane, Helicopters

Voluntary climate contribution

CO₂ emissions
0.15 kg
Climate contribution
CHF 0.11

Product dimensions

Length
4.70 cm
Width
2.20 cm
Height
1 cm
Diameter
22 mm
Weight
27 g
