ABB S2011C-B6 Circuit breaker 6kA 6A 1P+1P 1M

ABB Stotz S&J Circuit Breaker S2011C-B6

Manufacturer: ABB Stotz S&J
Description: Circuit breaker 6kA 6A 1P+1P 1M
Type: S2011C-B6
Installation depth: 17.8 mm
Tripping characteristic: B
Number of poles (total): 2
Number of protected poles: 2
Rated current: 6 A
Rated voltage: 240 V
Rated insulation voltage Ui: 500 V
Rated impulse voltage withstand Uimp: 4 kV
Rated switching capacity Icn according to EN 60898 at 230 V: 6 kA
Type of voltage: AC
Rated switching capacity Icu according to IEC 60947-2 at 230 V: 6 kA
Frequency: 50..60 Hz
Energy limitation class: 3
Flush-mounted: no
Overvoltage category: 3
Degree of pollution: 2
Additional devices possible: yes
Width in division units: 1
Protection class (IP): IP20
Ambient temperature during operation: -25..55 °C
Connectable conductor cross-section multi-stranded: 1..10 mm²
Connectable conductor cross-section single-stranded: 1..16 mm²
Explosion-proof: no

The circuit breakers of the S 200C series protect cables and wires against overload and short circuit according to DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1 and DIN VDE 0660-101 or IEC/EN 60947-2. Their terminal block ensures simple and secure connection and handling via a double-direction cylinder lift connection. Conductor cross-sections up to 16 mm² can be directly connected to the device via the terminal block with insulation in protection class IP20. The accessory range of the G2C series offers you flexible options to fulfill additional tasks. This device provides you with two separately protected connections in just one division unit (17.8 mm).
