Product details
ABB Stotz S&J Installation Contactor ESB25-22N-14
Manufacturer: ABB Stotz S&J
Designation: Installation Contactor 25A 12V AC/DC
Type: ESB25-22N-14
Rated Operating Voltage: 220..400 V
Rated Operating Current: 25 A
Utilization Category: 7
Rated Control Voltage: 12 V
Type of Operating Voltage: AC/DC
Type of Control Voltage: AC/DC
Number of Contacts as Normally Closed: 2
Number of Contacts as Normally Open: 2
Manual Control Lever: no
Width in Modular Units: 2
Installation Depth: 58 mm
Additional Devices Possible: yes
With Day/Night Function: no
Buzz-Free: yes
Protection Class (IP): IP20
ABB Stotz S&J Installation Contactor ESB25-22N-14: Additional Details
4-pole contactors ESB25..N with a width of 36 mm control 3-phase loads up to 25 A and are available in various contact configurations and coil voltages. They switch electrical heating devices, water heaters, motors for pumps, ventilation, and other drives as well as lighting. Thanks to an integrated coil circuit, they operate with both AC and DC control voltages. Therefore, the devices are completely buzz-free and quiet during switching. An auxiliary switch that can be mounted on the left side, sealing caps, and a spacer complement the range. ESB25..N features an installation design and comply with the household standard EN61095, making them particularly suitable for panel installation.
