ABB Current monitoring relay

ABB Stotz S&J Current Monitoring Relay CM-SRS.M1P

Manufacturer: ABB Stotz S&J
Designation: Current monitoring relay 2W B-C=3mA-1A
Type: CM-SRS.M1P
Type of electrical connection: Spring terminal connection
With removable terminals: no
Single-phase undercurrent possible: yes
Three-phase undercurrent possible: no
Single-phase overcurrent possible: yes
Three-phase overcurrent possible: no
Single-phase window possible: yes
Three-phase window possible: no
Includes DC undercurrent function: yes
Includes DC overcurrent function: yes
DC window function: yes
Rated control supply voltage Us at AC 50 Hz: 24..240 V
Rated control supply voltage Us at AC 60 Hz: 24..240 V
Rated control supply voltage Us at DC: 24..240 V
Type of voltage for operation: AC/DC
Current measuring range: 0.1..1 A
Min. adjustable response delay time: 0.1 s
Max. permissible response delay time: 30 s
Min. adjustable fallback delay time: 0.1 s
Max. permissible fallback delay time: 30 s
Number of contacts as changeover: 2
External current transformer: no
Width: 22.5 mm
Height: 85.6 mm
Depth: 103.7 mm

The CM series current monitoring relays protect single-phase networks (DC or AC) from overcurrents and undercurrents between 3 mA and 15 A. The devices with a maximum measuring range of 1 A are available in two different connection versions. You can choose between the proven screw connection technology (double chamber box connection terminals) and the tool-free Easy Connect connection technology (push-in terminals). Devices with a measuring range of up to 15 A are available with screw connection technology.
