Aaeon UPN-APLP4F-A10-0864 - UP Squared Pro Pentium Quad Core 08/64

UPN-APLP4F-A10-0864 - UP Squared Pro Pentium Quad Core 08/64
Following the success of UP Squared, the fastest x86 Pro Maker Board in the world, AAEON presents the UP Squared Pro.
The UP Squared Pro is based on the powerful Intel platform, formerly known as Apollo Lake, and is the latest addition to AAEON's extensive UP product line. It is designed for industrial use, enabling next-generation industrial automation and AI solutions with expansion capabilities for existing modules or AAEON's next generation of AI modules.
Unleash the future of industrial automation and AI vision with 5G connectivity and elevate your solutions to the PRO level.
The expansion cards are available in M.2 2230, M.2 2280, and M.2 3052 formats, providing options for project-specific requirements for the ultimate edge solution. The industrial setup of the board, featuring multiple serial ports, Ethernet ports (with TSN), 5G support, audio ports, and a range of other functionalities, makes it an ideal solution for various domains and products such as automation, robotics, drones, image processing, and the Internet of Things.
System Level
SoC: Intel Pentium N4200 (up to 2.5 GHz)
Number of Cores: 4
Graphics: Intel HD Graphics 500
VPU: Optional (via M.2 2280)
FPGA: Intel FPGA Altera MAX 10
MCU: N/A
Memory: 8 GB
eMMC: 64 GB
BIOS: UEFI
RTC: Yes
Wake on LAN (WoL): Yes
Watchdog Timer: Yes
PXE: Yes
Compatible Operating System: Microsoft Windows 10 Full Version, Linux (Ubuntu, Yocto)
Pre-installed Operating System: Optional Windows 10
Power Requirement: 12 ~ 24 V DC-IN (locking connector)
Power Supply Type: AT (Standard)/ATX
Typical Power Consumption: 20 Watts
Dimensions: 10.16 x 10.16 cm (4 x 4")
Operating Temperature: 32°F ~ 140°F (0°C ~ 60°C)
Storage Temperature: -40°C ~ 80°C
Operating Humidity: 0% ~ 90% relative humidity, non-condensing
MTBF (Hours): T.B.A.
Certification:...
