ABB S401M-D16 S401 M-D16 Miniature circuit-breaker
On this page you'll find a ranking of the best ABB products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
The S 400 series circuit breakers protect cables and wires from overload and short circuits in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN 60947-2. Their patented terminal block ensures easy and safe connection and handling via a pressure plate. Conductor cross-sections of up to 35 mm² can be directly connected to the device through the terminal block with insulation in protection class IP20. The connection is made directly via the plug-in socket system, and the external conductor connection can be freely selected (L1, L2, or L3). The extensive range of accessories provides everything you need for your installation tasks. Numerous approvals make the S 400 suitable for global use. Each device undergoes three intensive tests for quality and performance before delivery.
ABB S401M-D16 S401 M-D16 Miniature circuit-breaker
FI/LS switches (RCBOs) provide protection for people and property, as well as protection against electrically ignited fires in accordance with DIN VDE 0100-410 and DIN VDE 0100-530. They ensure the protection of single-phase circuits against overload and short-circuit currents, as well as protection against sinusoidal alternating currents and pulsating currents with a smooth residual direct current component of up to 6 mA to earth. Additionally, they offer fault protection (protection against indirect contact), supplementary protection, and fire protection. They comply with product standards IEC/EN 61009-1 (VDE 0664-20) and IEC/EN 61009-2-1 (VDE 0664-21). Their areas of application include household and commercial uses. The compact design of the DSX301C FI/LS is optimal for use in power distribution systems where space is limited. The series is equipped with a 30 mA differential fault current and a B or C tripping characteristic. Its patented connection terminals with Push-In technology ensure easy and secure contact and handling. The upper outgoing Push-In terminal can accommodate conductors of up to 2 x 4 mm². On the input side, PSX phase rails can be used for cross-wiring. For power supply, conductor cross-sections of up to 10 mm² can be directly connected to the device via the screw terminal in protection class IP20. For better visibility when connecting, the opening of the screw terminal is located above the flexible terminal for the phase rail. The rated switching capacity according to IEC/EN 61009 is Icn = 6 kA. The RCBO DSX301C Type A is single-pole protected (LS) and double-pole switching.
FI/LS switches provide personal and property protection as well as protection against electrically ignited fires in accordance with DIN VDE 0100-410 and DIN VDE 0100-530. They ensure the protection of single-phase circuits against overload and short-circuit currents, protection against sinusoidal alternating currents and pulsating currents with a smooth residual direct current component of up to 6 mA to earth. Additionally, they offer fault protection (protection against indirect contact), supplementary protection, and fire protection. They comply with the product standards IEC/EN 61009-1 (VDE 0664-20) and IEC/EN 61009-2-1 (VDE 0664-21). Applications include household, commercial, and industrial uses. The compact design of the DS301C FI/LS is ideally suited for use in power distributions where space is limited. The series is equipped with a 30 mA residual current and a B or C tripping characteristic. The rated breaking capacity according to IEC/EN 61009 is Icn = 6 kA. The RCBO DS301C Type A is single-pole protected (LS) and double-pole switching.
ABB's S 200 series circuit breakers protect cables and wires from overload and short circuits in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN 60947-2, and UL 1077. Their patented terminal block ensures easy and safe connection and handling through a pressure plate. For better visibility during wiring, the connection opening for wires is positioned above the connection opening for the phase bus. Wire cross-sections of up to 35 mm² can be directly connected to the device via the terminal block with insulation in protection class IP20. The extensive range of accessories provides everything you need for your installation tasks. Numerous approvals make the S 200 suitable for global use. Each device undergoes three intensive tests before delivery.
Current: 40A. Number of poles: 2. tripping sensitivity: 30mA. Tripping characteristic: Type A. Series: F202. DIN VDE 0664 part 11, DIN VDE 0664 part 1 // 10.85, EN 61008-2-1. residual current circuit-breaker, series F200. residual current circuit-breaker. 2- or 4-pole. Detect AC residual currents and pulsating DC residual currents. Shock current resistant up to 250A and therefore insensitive to short leakage currents to earth. DIN rail mounting. Signalling contact/auxiliary switch. 1 changeover contact. A maximum of three S2C-S/H6R can be connected in series.
The ABB S 200 series circuit breakers protect cables and wires from overload and short circuits in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN 60947-2, and UL 1077. Their patented terminal block ensures easy and safe connection and handling through a pressure plate. For better visibility during wiring, the connection opening for wires is located above the connection opening for the phase rail. Wire cross-sections of up to 35 mm² can be directly connected to the device via the terminal block with insulation in protection class IP20. The extensive range of accessories provides everything you need for your installation tasks. Numerous approvals make the S 200 suitable for worldwide use. Each device undergoes three intensive tests before delivery.
Number of poles: 4P
Rated current: 63A
Trip sensitivity: 300mA
AC rated voltage: 415V
Mounting type: DIN rail mounting
Range: Pro M compact
Series: DDA 200 A
IEC/EN 61009 RCD circuit breaker blocks, DDA 200A series. With integrated connection rail for right-flush mounting of 2-, 3-, and 4-pole miniature circuit-breakers of the S200 series. Neutral conductor connection can be made on the right or left. Application areas include escalators, elevators, electrically operated gates and barriers, machine tools, car washes, and conveyor belts.
ABB Stotz S&J Main Circuit Breaker S753DR-E50
Manufacturer: ABB Stotz S&J
Designation: Main Circuit Breaker 50A E 25kA 3P
Type: S753DR-E50
Tripping Characteristic: Other
Number of Poles: 3
Rated Current: 50 A
Rated Voltage: 400 V
Rated Insulation Voltage Ui: 690 V
Rated Short-Circuit Breaking Capacity: 25 kA
With Neutral Conductor: No
Frequency: 50 Hz
Overvoltage Category: 4
Degree of Pollution: 3
Rated Impulse Voltage Withstand: 6 kV
Mounting Type: DIN Rail
Protection Class (IP): IP20
Size (according to DIN 43880): 3
The selective main circuit breakers of the S750DR series are certified as voltage-independent selective main circuit breakers (SHU) according to DIN VDE 0641-21, designed for layman operation and suitable for the highest overvoltage category. Their application range is diverse: as a disconnection device at the meter location according to the TAB of the network operators or VDE-AR-N 4101, as well as in all low-voltage main distributions to protect distribution circuits and as a disconnection device with isolation function. Noteworthy are the special selectivity features that ensure high system availability. They are designed for mounting on a 35 mm top-hat rail according to DIN EN 60715. Devices of the S 750DR family include an integrated locking option that allows simultaneous blocking of the 3 poles of a three-phase supply. The integrated locking slider locks in the ON or OFF position and can additionally be secured with a padlock, wire seal, or cable tie. The switching state can be monitored via a mountable auxiliary switch.
ABB Stotz S&J Automatic circuit breaker S203MT-C16UC Manufacturer :ABB Stotz S&J Designation :Automatic circuit breaker 10kA 16A 3P Type :S203MT-C16UC Installation depth :69 mm Tripping characteristic :C Number of poles (total) :3 Number of fused poles :3 Rated current :16 A Rated voltage :440 V Rated insulation voltage Ui :484 V Rated impulse withstand voltage Uimp :4 kV Rated breaking capacity Icn to EN 60898 at 230 V :10 kA Voltage type :AC/DC Rated breaking capacity Icn to EN 60898 at 400 V :10 kA Rated breaking capacity Icu to IEC 60947-2 at 230 V :10 kA Rated breaking capacity Icu to IEC 60947-2 at 400 V :10 kA Frequency :50..60 Hz Energy limitation class :3 Flush mounting :no Switching neutral conductor :no Overvoltage category :3 Pollution degree :3 Additional devices possible :yes Width in pitch units :3 Protection class (IP) :IP20 Ambient temperature during operation :-25..55 °C Connectable conductor cross-section stranded :0.75..25 mm² Connectable conductor cross-section solid :0.75..35 mm² Explosion-proof :no ABB Stotz S&J automatic circuit-breaker S203MT-C16UC: further details The automatic circuit-breakers of the S 200 MT UC series protect cables and wires against overload and short-circuit in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN60947-2, hazard level R26/HL3 according to DIN EN 45545 and requirement class 3 according to NF F 16-101/102 (I2-F3) as well as category 1 - class A/B (mounted) according to IEC 61373. Their patented connection terminal ensures easy and safe contacting and handling by means of a pressure plate. For better visibility when wiring, the connection opening for cables is above the connection opening for the phase rail. Conductor cross-sections of up to 35 mm² can be connected directly to the unit via the terminal block with insulation in protection class IP20. The extensive range of accessories offers you everything you need for your installation tasks. The S200 MT UC impresses with its high short-circuit breaking capacity and flexible use for AC and DC applications. Each unit is subjected to three intensive tests for quality and performance before delivery. , EAN: 4013614447723.
The S 400 series circuit breakers protect cables and wires from overload and short circuits in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, and DIN VDE 0660-101 or IEC/EN 60947-2. Their patented terminal block ensures easy and secure connection and handling through a pressure plate. Conductor cross-sections of up to 35 mm² can be directly connected to the device via the terminal block with insulation in protection class IP20. The connection is made directly through the plug-in socket system, and the phase contact can be freely selected (L1, L2, or L3). The extensive range of accessories provides everything you need for your installation tasks. Numerous approvals make the S 400 suitable for worldwide use. Each device undergoes three intensive tests for quality and performance before delivery.
