Best Victron Energy products in the Power inverters category
On this page you'll find a ranking of the best Victron Energy products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Victron Energy Smart Orion-Tr 12/12/30
Charging booster Victron Smart Orion-Tr 12/12/30 Fully parameterisable charging converter Orion Smart with 3 charging levels, ideal for campers and boats. Suitable for Bluetooth Smart Monitoring, changing settings and updating the charger when new software functions become available can be done with any Bluetooth enabled smartphone, tablet or other device. Fully programmable battery charging algorithm (configurable) or fixed output. Intelligent generator compatibility: engine run detection. Adaptive 3-stage charging algorithm: constant current - constant voltage - conservation For lead-acid batteries, it is important to keep the recording time short during shallow discharges to avoid overcharging the battery. After a deep discharge, the constant voltage duration is automatically extended to ensure that the battery is fully charged. For lithium batteries, the recording time is fixed, by default 2 hours. Alternatively, a fixed output voltage can be selected. Remote on/off A remote on/off switch or relay contact can be connected to the two-pin connector. Alternatively, the H terminal (right) of the two-pole plug can be connected to a battery positive terminal or the L terminal (left) of the two-pole plug can be connected to the battery negative terminal (or to the body of a vehicle, for example). All models are short-circuit proof and can be connected in parallel to increase the output current. An unlimited number of units can be connected in parallel. Overtemperature protection The output current is reduced at high ambient temperatures. Protection class IP43 When the screw terminals on the unit are installed facing downwards. Screw terminals No special tools are required for installation. Input fuse (not replaceable) Scope of delivery: 1 x charge booster 1 x operating manual
2. Victron Energy Phoenix 12/500 PU
The Victron Phoenix 12/500VE.Direct is a small sine wave inverter with 400 W continuous power. This inverter is supplied with a Schuko socket.
Victron Phoenix 12/500VE
For short periods it can deliver up to 900 W to supply high inrush currents of LED lighting, electrical appliances or motors. The Phoenix 12/500VE.Direct is suitable for connection to batteries with 12 V DC voltage and converts this to a pure 230 V sine wave AC voltage. With an efficiency of 90%, it is one of the best devices in its class. Via the VE.Direct connection, the device can be connected to a computer or smartphone and various parameters can be configured.
Configure parameters
The inverter is ready to use with factory settings and can be configured using a computer (VE.Direct to USB interface cable required), Apple and Android smartphone, tablet or using other devices (VE.Direct Bluetooth Smart Dongle required). Among others, the output AC voltage and output frequency, the low battery alarm threshold and shutdown voltage, and the battery charged status detection voltage. Also configurable are the settings for ECO mode stop and power start.
ECO mode
Set the front panel switch to ECO mode to reduce power consumption in no-load mode. The inverter then switches off automatically as soon as it detects that no loads are connected. It then switches on briefly every 2.5 seconds to check whether a load is present. If the output power exceeds the set limit, the inverter resumes operation. These parameters are also configurable.
Remote on/off switching
A remote on/off switch can be connected to the two-pin connector. Or the left contact of the plug can be switched to the positive battery terminal: This is useful in automotive applications. Wire it to the ignition contact.
3. Victron Energy VE TR 24/12-5 - DC/DC converter, 12.7 V, 5 A
Orion-Tr DC/DC converter 24/12V 5 Amp - non-isolated
Voltage converter with fixed output voltage, by synchronous rectification the efficiency reaches more than 95 %.
IP43 protection: When the unit is installed with the screw terminals facing downwards.
4. Victron Energy Phoenix VE.Direct Schuko 12/1200
SinusMax cutting-edge technology
The Phoenix inverter series was developed for commercial use; it is suitable for a wide range of applications. The development aimed uncompromisingly at an inverter with clean sine wave output at high efficiency. By applying the latest hybrid HF technology, it was possible to present a quality product with compact dimensions and low weight that can easily deliver any desired power.
VE.Direct / Bluetooth Dongle Connection: Convenient Device Monitoring with Smartphone
With the help of the VE.Direct connection, the inverter can be connected to a PC or cell phone.
It is also possible to keep an eye on the status of the device with the cell phone.
Highest starting power
A key feature of SinusMax technology is its particularly high starting power. This is not possible with conventional HF technology. Phoenix inverters are capable of handling the high starting currents of, for example, cooling compressors, tool motors and the like. Load switching to other AC sources: The automatic load transfer switch For smaller power ratings, we recommend the Filax automatic transfer switch. Computers and other sensitive electronic equipment can thus continue to operate practically without interruption, since the switching times are very short (less than 20 msec).
ECO mode
In ECO mode, the inverter switches to standby as soon as the load drops below a preset value (minimum load: 15 W). In standby mode, the inverter then switches on for a short period of time (adjustable default setting: every 2.5 seconds). If the load exceeds a preset threshold in the process, the inverter remains switched on.
Proven reliability
The complete bridging additionally with a ring transformer topology has proven itself for years. The inverters are short-circuit proof and protected against overheating (whether caused by overload or ambient temperature).
Fully configurable:
Thresholds to trigger and reset alarms when the battery is low.
Thresholds to switch off and restart at low battery voltage values.
Dynamic shutdown: load-dependent shutdown threshold value.
Output voltage 210 - 245 V
Frequency 50 Hz or 60 Hz
Threshold for ECO mode on/off and ECO mode sensor
Monitoring: input and output voltage, % load and alarms.
5. Victron Energy Buck-Boost 25A DC/DC converter
Buck-Boost DC-DC Converter 25A
DC-DC converter for charging a 12V/24V service battery in vehicles with an intelligent alternator.
The DC-DC converter Buck-Boost is a DC-DC converter for charging a 12V/24V service battery in vehicles with an intelligent alternator. As these alternators (driven by the on-board electronics of Euro 5 and 6 engines) do not always output the correct charging current, a DC-DC converter is crucial to charge the service battery correctly.
Furthermore, it is almost inevitable to use a booster to charge a lithium battery. Since lithium batteries have a very low internal resistance, they draw as much current as the alternator can supply. This can lead to an overload of the alternator and / or the wiring. A booster limits this current. Only with the Buck Boost can the charging current be freely adjusted.
6. Victron Energy Orion-Tr 12/12-9A DC-DC
Remote on/off switch The remote on/off switch eliminates the need for a high-current switch on the input wiring. The remote on/off connection can be controlled with a power-saving switch or by the motor's run/stop switch (see manual). Adjustable output voltage: Can also be used as a battery charger For example, to charge a 12 volt starter or auxiliary battery in an otherwise 24 volt system. All models are short-circuit proof and can be connected in parallel to increase the output current. An unlimited number of units can be connected in parallel. IP43 protection: When the unit is installed with the screw terminals facing downwards. Screw terminals: No special tools are required for installation. Input fuse: Only on the 12 V and 24 V models: 12 / 24 / 48 volts.
7. Victron Energy Multiplus 12/500/20-16
The Multiplus is a powerful pure sine wave inverter, an advanced battery charger utilising adaptive charging technology and a high-speed AC voltage transfer switch in a single compact housing. In the event of a mains fault or if the shore power or on-board generator is interrupted, the Multi's inverter is automatically switched on and takes over the supply to the connected loads. The switchover happens so quickly (in less than 20 milliseconds) that uninterrupted operation of computers and other electronic devices is guaranteed.
8. Victron Energy Victron Orion-Tr 24/12-20 240W DC DC Converter Converter - non-isolated
The Victron Orion-Tr 24/12-20 240W DC DC converter - non-isolated (MPN ORI241220200) provides regulated DC voltage for trouble-free operation of your electronic DC loads. The 24/12 converts 24V DC to 12V DC and delivers a constant continuous current of 20A which equates to 240W of power. It provides a clean 12V output voltage and compensates for any line losses as well as fluctuations in battery voltage. Key features of the Orion-Tr 24/12 20A 240W 24V DC operating voltage, 12V DC output voltage Wide input voltage range: 18V - 35V 240W power at 5 A continuous current Efficiency: 95% Connection: Screw terminals max 6 mm² AWG10 Version not insulated Scope of delivery: 1x Victron ORI241220200 Orion 24/12-20 DC DC converter 24V to 12V 20A 240W.
Victron Energy Victron Orion-Tr 24/12-20 240W DC DC Converter Converter - non-isolated
9. Victron Energy Victron Orion-Tr 24/12-15 180W DC DC Converter Converter - non-isolated
The Victron Orion-Tr 24/12-15 180W DC DC converter - non-isolated (MPN ORI241215200R) provides regulated DC voltage for trouble-free operation of your electronic DC loads. The 24/12 converts 24V DC to 12V DC and delivers a constant continuous current of 15A which equates to 180W of power. It provides a clean 12V output voltage and compensates for any line losses as well as fluctuations in battery voltage. Key features of the Orion-Tr 24/12 15A 180W 24V DC operating voltage, 12V DC output voltage Wide input voltage range: 18V - 35V 180W power at 5 A continuous current Efficiency: 95% Connection: screw terminals max 6 mm² AWG10 version Non-insulated Scope of delivery: 1x Victron ORI241215200R Orion 24/12-15 DC DC converter 24V to 12V 15A 180W.
Victron Energy Victron Orion-Tr 24/12-15 180W DC DC Converter Converter - non-isolated
10. Victron Energy DCDC converter Victon Orion Tr 20A
Remote on/off switching
The remote on/off circuit eliminates the need for a high current switch on the input wiring. The remote on/off connection can be controlled with a power-saving switch or by the motor's Run/Stop switch.
Adjustable output voltage: can also be used as a battery charger.
For example, to charge a 12 volt starter or auxiliary battery in an otherwise 24V system. All models are short circuit proof and can be connected in parallel to increase the output current.
increase the output current. An unlimited number of devices can be connected in parallel.
High temperature protected
At high ambient temperature the output current is reduced.
