Best selling Network cables from Klotz
On this page you'll find a ranking of the best Klotz products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. Klotz C6AUFEH-D
Data cable for the transmission of analog and digital signals in the frequency range up to 500 MHz. It is designed for cabling in the primary, secondary, and tertiary areas. Suitable for IEEE 802.3 10/100/1000/10GBase-T, FDDI, broadband, video, ISDN, ATM, PoE.
2. Klotz RamCAT RCBEED070
Double-shielded RamCAT data cable with solid inner conductors, PE cross, and PUR outer sheath. Thanks to the AWG24 solid conductors, it allows EtherSound transmission up to 120 meters. Its suitability for mobile use is achieved through a special design with a cross-shaped stranding element and a wear-resistant PUR outer sheath. The foam-skin PE conductor insulation enables direct assembly with standard RJ45 connectors.
3. Klotz RC5EE200V
The RC5EE200V network cable from Klotz Technics is a highly flexible RamCAT cable specifically designed for demanding outdoor use. With a length of 20 meters, it provides a reliable connection for various network devices. The cable is made from durable Cat. 5 Outdoor S/UTP and features a robust PUR outer jacket that protects it from external influences. The wiring follows the TIA/EIA 568-B standard, ensuring high compatibility with common network applications. The maximum bandwidth is up to 100 MHz, making it ideal for data transmission in professional environments. The cable is equipped with two CAT5e etherCON RJ45 connectors that enable a secure and stable connection.
- Highly flexible design for outdoor use
- Durable Cat. 5 Outdoor S/UTP cable
- Robust PUR outer jacket for added protection
- Wiring according to TIA/EIA 568-B standard
- Maximum data transmission rate of up to 100 MHz.
4. Klotz RC5RR075V
The Klotz Technics RC5RR075V is a highly flexible RamCAT network cable specifically designed for demanding outdoor use. With a length of 7.5 meters, it provides a reliable connection for various network applications. The cable features a durable PUR outer jacket that protects it from external influences and ensures a long lifespan. The wiring follows the TIA/EIA 568-B standard, allowing for easy integration into existing networks. With a maximum bandwidth of up to 100 MHz, it ensures stable data transmission, while the shielded RJ45 CAT5e connectors at both ends provide a secure connection. This cable is ideal for use in professional environments where flexibility and robustness are required.
- Durable Cat. 5 Outdoor, S/UTP, AWG26 stranded wire
- PUR outer jacket for additional protection
- Maximum data transmission rate of 100 MHz
- Wiring according to TIA/EIA 568-B standard
- Professional shielded RJ45 CAT5e connectors at both ends.
5. Klotz RC5C-EE001.0B
Resistant CAT5e outdoor S/UTP AWG26 stranded wire
Assignment according to TIA/EIA 568-B
PUR outer jacket
Max. bandwidth: ≤ 60 m = 100 MHz; > 60 m < 100 MHz
The RamCAT Litz High Flex is an extremely robust reeling cable designed for mobile use as a data cable. It has proven its performance in tests by many manufacturers: Yamaha UK recommends it for Dante™ up to 75 metres, DigiGram for EtherSound up to 75 metres, and Allen & Heath for iLive ACE/dSnake up to 100 metres.
6. Klotz RamCAT RC6ARRW080
The RamCAT6A cable RC6A-SB1X for data transmission in mobile operations is designed for a frequency of 500 MHz, making it suitable for data transfer rates of up to 10 Gbit/s over a link length of up to 100 m. It is primarily used for data transmission in Ethernet applications 1000Base-T and 10GBase-T on cable drums. This robust data line features a characteristic impedance of 100 Ohms and consists of four twisted pairs with AWG 23/1 solid conductors, making it the 'big brother' of our best-selling 'universal cable' RC5-SB1X. The coordinated twist lengths of the individual pairs and the sophisticated overall twisting using a PE twisting element ensure extremely low NEXT (near-end crosstalk) and FEXT (far-end crosstalk) values. Thanks to the cross-shaped PE twisting element, the stabilizing intermediate layer, and the abrasion-resistant PUR outer sheath, the cable is suitable for mobile road use (Touring Grade). A double shielding (SF/UTP) reliably protects against electromagnetic interference. For a suitable connector, we recommend the Telegärtner MFP8 IE series made of metal. The RamCAT6A cable is available both as bulk cable and as premade cables with and without cable drums.
7. Klotz RamCAT RC6ARRW050
The RamCAT6A cable RC6A-SB1X for data transmission in mobile operations is designed for a frequency of 500 MHz, making it suitable for data transfer rates of up to 10 Gbit/s over a link length of up to 100 m. It is primarily used for data transmission in Ethernet applications 1000Base-T and 10GBase-T on cable drums. This robust data line, with a characteristic impedance of 100 Ohms, features four twisted pairs with AWG 23/1 solid conductors, making it the 'big brother' of our best-seller and 'universal cable' RC5-SB1X. The coordinated lengths of the individual pairs and the sophisticated overall twisting using a PE twisting element ensure extremely low NEXT (near-end crosstalk) and FEXT (far-end crosstalk) values. Thanks to the cross-shaped PE twisting element, the stabilizing intermediate layer, and the abrasion-resistant PUR outer sheath, the cable is suitable for mobile road use (Touring Grade). A double shielding (SF/UTP) effectively protects against electromagnetic interference. For a compatible connector, we recommend the Telegärtner MFP8 IE series made of metal. The RamCAT6A cable is available both as bulk cable and as premade cables with and without cable drums.
8. Klotz RamCAT CP5RR1PW60
Flexible data cable for the transmission of analog and digital signals in the frequency range up to 200 MHz. It is suitable as a device connection and patch cable in patch panels. Designed for use in Class D applications such as 10Base-T, 100Base-T, 1000Base-T, Token Ring, FDDI, ISDN, ATM, audio networks like EtherSound, and DMX lighting controls. The cable meets the requirements for category 5e patch cables according to ISO/IEC 11801, EN 50173-1, IEC 61156-6, and EN 50288-2-2. The version with a PUR outer sheath is extremely abrasion-resistant, flexible at temperatures down to -40°C, and resistant to oil, microbes, and chemicals.
9. Klotz RCBEEW050 RC5SB Drum 50 metre UTP cable op haspel
Double-shielded RamCAT data cable with solid inner conductors, PE cross and PUR outer sheath. Thanks to the AWG24 solid conductors, it allows EtherSound transmission up to 120 meters. Its suitability for mobile use is achieved through the special design with a cross-shaped stranding element and a wear-resistant PUR outer sheath. The foam-skin PE insulation allows for direct termination with standard RJ45 connectors.
Network cables
CHF689.– CHF13.78/1m
Klotz RCBEEW050 RC5SB Drum 50 metre UTP cable op haspel
U/FTP, CAT7, 50 m
10. Klotz RamCAT RC6EEW0600
Double-shielded RamCAT data cable with solid inner conductors, PE cross and PUR outer sheath. Thanks to AWG24 solid conductors, it supports EtherSound up to 120 meters. Its suitability for mobile use is achieved through the special design with a cross-shaped stranding element and a wear-resistant PUR outer sheath. The foam-skin PE insulation allows for termination with the etherCON connectors commonly used in live operations.
