Zotac ZBOX PRO CI329 nano

Intel Celeron N4100
10Ratings
Currently out of stock

Product details

The performance and versatility of the ZBOX Pro CI329 nano make it particularly unique. Equipped with an Intel Celeron N4100 processor, the ZBOX features solid Intel UHD graphics and stands out for its exceptional efficiency in resource-intensive applications. It offers strong performance for a wide range of applications, from research laboratories to Ultra-HD digital signage solutions. Thanks to its fanless design, this device can be easily installed in even the most sound-sensitive environments. Additionally, the ZBOX Pro comes with a variety of connectivity options, including HDMI, DisplayPort, VGA, a serial RS-232 port, USB 3.0 ports, and dual Gigabit Ethernet.

Key specifications

Number of processor cores
4 -Core
Graphics card model
UHD Graphics 600
Internal connection options
M.2 (1x), S-ATA III (1x)
Network connections
RJ45 (2x)
Video connections
DisplayPort (1x), HDMI (1x), VGA (1x)
Memory type
DDR4-RAM
USB ports
USB-A
Item number
11057337

General information

Manufacturer
Zotac
Category
Barebones
Manufacturer no.
ZP-CI329NANO-BE
Release date
8.5.2019
External links
Manufacturer's site (de)

Barebone properties

Design
Small Form

Processor

Processor type
Intel Celeron N4100
Clock frequency
1.10 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Number of threads
4
Socket
BGA 1090
Max. turbo clock rate
2.40 GHz
Max. TDP
6 W
Processor properties
64-bit architecture, Onboard processor

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Number of pins
260 x
Memory chip compatibility
DDR4-2400
Memory Slots available
2
Max. memory slots
2
Max. RAM
8 GB

Graphics card properties

Graphics card model
UHD Graphics 600
Max. connected monitors
2 x

Internal connections

Internal connection options
M.2 (1x), S-ATA III (1x)
"Number of 2.5"" drive slots"
1 x

External connections

USB ports
USB-A
Exact USB ports
USB-A 3.1 Gen 1 (3x)
Data ports
RS-232 (1x)

Network

Network connections
RJ45 (2x)
Max. port speed
1000 Mbit/s

Wireless transmission

Connectivity
WLAN
Wi-Fi standard
Wi-Fi 1 / 802.11b, Wi-Fi 2 / 802.11a, Wi-Fi 3 / 802.11g, Wi-Fi 4 / 802.11n, Wi-Fi 5 / 802.11ac

Video connections

Video connections
DisplayPort (1x), HDMI (1x), VGA (1x)

Audio connections

Audio outputs
3.5mm jack (1x)

Card reader properties

Memory card type
SD, SDHC, SDXC

Power supply properties

Power
40 W
Fan diameter
0 mm

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
1x Dual-Band Antenna, 1x L-shaped Mounting Kit, 1x VESA holder, 2x screw set, Power supply, User guide

Product dimensions

Width
126.70 mm
Length
160 mm
Height
58.70 mm

Package dimensions

Length
28.80 cm
Width
21.20 cm
Height
11.10 cm
Weight
2 kg
