Zotac ZBOX Magnus One

Intel Core i7-14700
Ratings
Currently out of stock
Free shipping starting at 50.–

Product details

The ZOTAC ZBOX MAGNUS ONE ERP74070SW is a mini PC that offers performance in a compact form factor. Equipped with an Intel Core i7 processor that operates at a base clock speed of 2.1 GHz and can reach turbo speeds of up to 5.4 GHz, it handles demanding tasks with ease. The system supports up to 12 GB of GDDR6 SDRAM from its NVIDIA GeForce RTX 4070 SUPER graphics processor, making it suitable for gaming, content creation, and other resource-intensive applications. Additionally, the ZBOX MAGNUS ONE features numerous connectivity options such as HDMI, DisplayPort, USB 3.0, USB 3.1, and Thunderbolt 4. It supports networking through two 2.5 Gigabit Ethernet ports and includes Bluetooth 5.2 and Wi-Fi 6 for wireless performance. With a power output of 500 watts provided by an 80 PLUS Platinum certified power supply, this system ensures efficiency and reliability for a variety of applications.

Key specifications

Number of processor cores
20 -Core
Graphics card model
GeForce RTX 4070 Super
Network connections
RJ45 (1x)
Video connections
DisplayPort (3x), HDMI (1x)
Memory type
DDR5 RAM
USB ports
Thunderbolt 4, USB-A, USB-C
Item number
49042628

General information

Manufacturer
Zotac
Category
Barebones
Manufacturer no.
ZBOX-ERP74070SW-BE
Release date
3.9.2024

Barebone properties

Design
Small Form

Processor

Processor type
Intel Core i7-14700
Clock frequency
2.10 GHz
Number of processors
1 x
Number of processor cores
20 -Core
Socket
LGA 1700
Max. turbo clock rate
5.40 GHz

Memory

Memory type
DDR5 RAM
Memory form factor
SO-DIMM
Max. RAM
64 GB

Graphics card properties

Graphics card model
GeForce RTX 4070 Super

External connections

USB ports
Thunderbolt 4, USB-A, USB-C
Exact USB ports
USB-A 3.0 (2x)

Network

Network connections
RJ45 (1x)
Max. port speed
1000 Mbit/s

Wireless transmission

Wi-Fi standard
Wi-Fi 6 / 802.11ax
Bluetooth version
5.2

Video connections

Video connections
DisplayPort (3x), HDMI (1x)

Power supply properties

Power
500 W

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
2 antennas

Product dimensions

Width
126 mm
Length
265.50 mm
Height
249 mm

Package dimensions

Length
44 cm
Width
21 cm
Height
33 cm
Weight
6.20 kg
