Zotac Zbox Edge MI646

Intel Core i5-1135G7
Ratings
Delivered between Mon, 4.8. and Tue, 2.9.
Supplied by

Product details

Ultrathin design meets next-generation performance in the new ZBOX M-Series Edge. Powered by the latest 11th generation Intel Core processor, integrated with powerful Iris Xe graphics and support for 3200 MHz DDR4 high-speed memory and Thunderbolt 4, the ZBOX Edge MI646 offers full desktop PC functionality and flexibility in an ultra-slim form factor.

Key specifications

Number of processor cores
4 -Core
Graphics card model
Iris Xe Graphics
Internal connection options
S-ATA (1x)
Network connections
RJ45 (1x)
Video connections
HDMI (1x), Thunderbolt 4 (1x)
Memory type
DDR4-RAM
USB ports
Thunderbolt, USB-A
Item number
18474900

General information

Manufacturer
Zotac
Category
Barebones
Manufacturer no.
ZBOX-MI646-BE
Release date
15.1.2022

Barebone properties

Design
Ultra Slim

Processor

Processor type
Intel Core i5-1135G7
Clock frequency
2.40 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Number of threads
8
Socket
FCBGA1449
Max. turbo clock rate
4.20 GHz
Max. TDP
65 W
Processor properties
64-bit architecture

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Memory chip compatibility
DDR4-2666, DDR4-3200
Memory Slots available
2
Max. memory slots
2
Max. RAM
64 GB
Memory voltage
1.50 V

Graphics card properties

Graphics card model
Iris Xe Graphics
Hardware application range
Workstations

Internal connections

Internal connection options
S-ATA (1x)

External connections

USB ports
Thunderbolt, USB-A
Exact USB ports
USB-A 3.0 (3x)

Network

Network connections
RJ45 (1x)
Max. port speed
1 Mbit/s

Wireless transmission

Connectivity
Bluetooth, WLAN
Wi-Fi standard
Wi-Fi 5 / 802.11ac
Bluetooth version
5.0

Video connections

Video connections
HDMI (1x), Thunderbolt 4 (1x)

Audio connections

Audio outputs
3.5mm headphones

Card reader properties

Memory card type
microSD, microSDHC, microSDXC

Power supply properties

Power
65 W

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Power adapter, Power cord, USB stick, Wall mount, Wi-Fi antenna

Product dimensions

Weight
2000 g
Width
149.50 mm
Length
149.50 mm
Height
28.50 mm

Package dimensions

Length
24 cm
Width
23 cm
Height
9 cm
Weight
100 g

30-day right of return
24 Months Warranty (Bring-in)
