Zotac ZBOX-CI645NANO I5-1135G7 Intel DDR4 HDMI DP

Intel Core i5-1135G7
2Ratings
Currently out of stock

Product details

The ZBOX CI645 Nano is so small that it can be used in environments with limited space. It is the ideal PC for home theater, digital signage, home office, office workstations, and much more.

Key specifications

Number of processor cores
4 -Core
Graphics card model
Intel Iris Graphics
Internal connection options
M.2 (1x)
Network connections
RJ45 (2x)
Video connections
DisplayPort (1x), HDMI (1x)
Memory type
DDR4-RAM
USB ports
Thunderbolt, USB-A
Item number
17552166

General information

Manufacturer
Zotac
Category
Barebones
Manufacturer no.
ZBOX-CI645NANO-BE
Release date
11.11.2021

Barebone properties

Design
All-in-one

Processor

Processor type
Intel Core i5-1135G7
Clock frequency
2.40 GHz
Number of processors
1 x
Number of processor cores
4 -Core
Socket
FCBGA1449
Max. turbo clock rate
4.20 GHz
Max. TDP
65 W

Memory

Memory type
DDR4-RAM
Memory form factor
SO-DIMM
Number of pins
260 x
Max. memory slots
2
Max. RAM
64 GB

Graphics card properties

Graphics card model
Intel Iris Graphics

Internal connections

Internal connection options
M.2 (1x)

External connections

USB ports
Thunderbolt, USB-A
Exact USB ports
Thunderbolt 4 (1x), USB-A 3.2 Gen 1 (4x)

Network

Network connections
RJ45 (2x)
Max. port speed
1000 Mbit/s

Wireless transmission

Connectivity
WLAN
Wi-Fi standard
Wi-Fi 5 / 802.11ac
Bluetooth version
5.0

Video connections

Video connections
DisplayPort (1x), HDMI (1x)

Audio connections

Audio outputs
Headphones Out (1x)

Card reader properties

Memory card type
SD, SDHC, SDXC

Power supply properties

Power
65 W

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
USB, Wireless antenna, Wireless antenna, USB flash drive, VESA mounting kit

Product dimensions

Weight
2092 g
Width
204 mm
Length
129 mm
Height
68 mm

Package dimensions

Length
24 cm
Width
24 cm
Height
9.60 cm
Weight
2.09 kg
