Wago 771-9985/006-301, 3 m, Male/Female, Black, Blue

Ratings
Currently out of stock
Free shipping starting at 50.–

Product details

WAGO GmbH & Co. KG connecting cable 771-9985/006-301

Manufacturer: WAGO GmbH & Co. KG
Designation: Connecting cable 5-pole, black
Type: 771-9985/006-301
Rated voltage: 400 V
Rated current: 16 A
Number of poles: 5
Protection class (IP): IP20
Type of cable assembly: Connecting cable
Version side 1: Socket
Version side 2: Plug
Conductor end treatment: Ultrasonically compacted wire ends
Total length: 3000 mm
Mechanical coding: Yes
Colour of coding/contact insert: Blue
Housing colour: Black
Cable type: H05VV-F
Cable diameter: 9.3 - 11.6 mm
Sheath colour: Black
Nominal conductor cross-section: 1.5 mm²
Type of interlock: Separate
Insulating part withstands continuous temperatures up to: 105 °C
Cable withstands continuous temperatures up to: 70 °C
Max. operating temperature at conductor: 75 °C
Halogen-free: No
Fire load: 25.07167 kWh
Surface treatment contacts: Tin-plated
Degree of contamination: 3
Contact resistance: 1 mOhm
Rated impulse voltage: 6 kV
Fire behaviour class according to EN 13501-6: Eca

WAGO GmbH & Co. KG connecting cable 771-9985/006-301: more details prefabricated connecting cable Eca socket plug 5-pole cod. I H05VV-F 5G 1.5 mm² 3 m 1.50 mm² blue.

Key specifications

Cable + connector type
Plug connectors
Cable length
3 m
Item number
36258812

General information

Manufacturer
Wago
Category
Cables + Plugs
Manufacturer no.
771-9985/006-301
Release date
14.6.2023

Colour

Colour
Black

Cable + Connector Features

Cable + connector type
Plug connectors
Max. temperature
85 °C
Min. temperature
10 °C
Cable length
3 m
Manufacturer Type
006-301, 771-9985
Connectors Design
Flange bushing
Number of cores
5 x

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
300 cm
