Wago 734-104

Minimum order 5
Ratings
Delivered between Tue, 22.7. and Wed, 23.7.
More than 10 pieces in stock at third-party supplier
Supplied by
Free shipping starting at 50.–

Product details

WAGO GmbH & Co. KG female connector 734-104

Manufacturer: WAGO GmbH & Co. KG
Description: Female connector 4p 3.5mm light grey
Type: 734-104
Connection type: PCB to cable
Contact design: Female
Number of poles: 4
Number of rows of plug-in contacts: 1
Contact pitch: 3.5 mm
Terminal pitch: 3.5 mm
Angle contact/conductor connection: 180° (horizontal)
Rated current: 10 A
Rated voltage: 160 V
Rated impulse voltage: 2.5 kV
Overvoltage category: III
Pollution degree: 2
Connectable conductor cross-section, fine-stranded without ferrule: 0.08 to 1.5 mm²
Connectable fine-stranded conductor cross-section with ferrule: 0.25 to 1.5 mm²
Connectable solid conductor cross-section: 0.08 to 1.5 mm²
Connectable conductor cross-section stranded: 0.08 to 1.5 mm²
Electrical connection type: Spring-loaded connection
Connectable cable type: Round cable
Material of contact coating: Tin
Material of contact: Other copper alloys
Material of insulating body: Thermoplastic
Material of housing: Plastic
Coating of housing: Uncoated
Housing colour: Grey
Flammability class of insulating material according to UL 94: V0
With protective conductor: No
Operating temperature: -60 to 100 °C
Protection class (IP), mounted: IP20

WAGO GmbH & Co. KG female connector 734-104: further details
1-conductor female connector CAGE CLAMP® 1.5 mm²
Spacing: 3.5 mm
4-pole
100% mismating protected
1.50 mm² light grey
EAN: 4044918492478.

Key specifications

Cable + connector type
Plug connectors
Cable length
0.02 m
Item number
34027242

General information

Manufacturer
Wago
Category
Cables + Plugs
Manufacturer no.
734-104
Release date
17.5.2023
Minimum order
5
Minimum order
5

Colour

Colour
Grey

Material

Material group
Plastic
Material
PA 66, Pewter, Plastic, Thermoplastic resin

Cable + Connector Features

Cable + connector type
Plug connectors
Max. temperature
100 °C
Min. temperature
-60 °C
Cable length
0.02 m
Manufacturer Type
734-104
Connectors Design
Socket, straight
Number of cores
4 x

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
100 Piece
Scope of delivery
1x WAGO 734-104

Product dimensions

Length
1.34 cm
Width
1.86 cm
Height
1.10 cm
