Turck Valve plug connector type CI Connection cable VC9S02-A80E-5/TXL

Ratings
Delivered between Tue, 2.9. and Thu, 18.9.

Product details

Turck valve connector VC9S02-A80E-5/TXL Manufacturer :Turck Designation :Valve connector Design CI Type :VC9S02-A80E-5/TXL Number of poles :3 Type of electrical connection, housing side :other Type of plug contact, housing side :Male Cable length :5 m Cable sheath material :Polyurethane (PUR) Cable sheath colour :black With LED indicator :no Shielded :no Cable type :multicore Contact body material :CuSn Contact coating material :silver Perm. External cable temperature after installation without vibration :-40..80 °C Perm. Permissible external cable temperature during installation/handling :-30..90 °C Rated current In :4 A Rated voltage :230 V Turck valve connector VC9S02-A80E-5/TXL: further details Valve connector design CI, connection cable, 2-pin + PE, design according to standard DIN EN 175301-803, RoHS-compliant, protection class: IP65, IP67, IP68, without protective circuit, without LED, cable length: 5.0 metres, sheath material: PUR, sheath colour: black, suitable for drag chains, resistant to welding sparks, resistant to chemicals and oil, UV and ozone resistant, flame retardant, halogen, silicone, PVC and LABS-free, EAN: 4047101373691.

Key specifications

Plug type
DC connector
Cable + connector type
Plug connectors
Cable length
5 m
Item number
36622423

General information

Manufacturer
Turck
Category
Cables + Plugs
Manufacturer no.
6606904
Release date
22.6.2023

Colour

Colour
Black

Material

Material group
Plastic
Material
Polyurethane (PUR)

Cable + Connector Features

Cable + connector type
Plug connectors
Plug type
DC connector
Max. temperature
80 °C
Min. temperature
-40 °C
Cable length
5 m
Manufacturer Type
TXL, VC9S02-A80E-5
Number of cores
3 x

Origin

Country of origin
China

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece
Scope of delivery
2-pole + PE, Cable length: 5.0 metres, Coat colour: black, Connection cable, Design according to standard DIN EN 175301-803, Flame retardant, Halogen, Ip67, IP68, Jacket material: PUR, Protection class: IP65, PVC- and LABS-free, Resistant to chemicals and oil, RoHS-compliant, Silicone, Suitable for drag chains, sweat spark-proof, UV and ozone resistant, Valve connector type CI, without LED, without protective circuit

Product dimensions

Length
500 cm
