Telegärtner 7-16 Flange connector AG/AG 50 Ohm

The Series 7-16 (DIN) are widely used coaxial connectors in the mobile communications sector. These robust connectors feature a screw lock and are waterproof. Depending on the design, they can be used at frequencies of up to 7.5 GHz. The connectors in the 7-16 series have a characteristic impedance of 50 Ω. Connector variants are available for flexible, semi-flexible, semi-rigid, and corrugated cables. Cables can be connected through soldering, crimping, or clamping. These connectors are particularly used in mobile communications. Additionally, they are also employed for testing purposes where resistance to vibration and weather is required. The special design of the 7-16 connectors ensures excellent performance in return loss (VSWR) and intermodulation resistance. 7-16 connectors are suitable for transmitting high power at high frequencies. These connectors meet the ingress protection rating in the mated condition between plug and socket according to IP 68. This protection class has been generally established for the 7-16 series. Individual connectors may vary. In case of doubt, please inquire.
