Supermicro M12SWA-TF

sWRX8, AMD WRX80, E-ATX
Ratings
Delivered between Tue, 27.5. and Wed, 28.5.
Only 2 items in stock at third-party supplier
Supplied by

Product details

The Super Micro Computer M12SWA-TF motherboard is a high-end server motherboard designed to meet the needs of data centers and demanding workloads. It supports 2nd generation AMD EPYC processors with up to 64 cores and 128 threads, as well as eight channels of DDR4 memory with ECC support for maximum data security and reliability. The motherboard features an SP3 socket and supports both PCIe 4.0 and PCIe 3.0 slots to provide a wide range of expansion options. It also offers multiple networking and storage options, including 10GbE network connections and NVMe storage.

Key specifications

Processor family
Ryzen Threadripper Pro
Memory type
DDR4-RAM
Number of memory modules (RAM)
8 x
Internal connection options
S-ATA III (4x)
Mainboard features
Trusted Platform Module
Item number
15710570

General information

Manufacturer
Supermicro
Category
Motherboards
Manufacturer no.
MBD-M12SWA-TF-O
Release date
24.6.2024

Motherboard properties

Form factor
E-ATX
Socket
sWRX8
Chipset
AMD WRX80
Mainboard features
Trusted Platform Module
BIOS type
Ami

Processor

Processor family
Ryzen Threadripper Pro

Memory

Memory form factor
DIMM
Number of pins
240 x
Number of memory modules (RAM)
8 x
Max. memory (RAM)
2000 GB
Memory chip
DDR4 RAM
Supported memory speed
2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz, 3000 MHz, 3200 MHz
Transfer rate
10 MT/s
Memory type
DDR4-RAM
RAM buffer
Unbuffered

Graphics properties

Video connections
D-Sub (1x)

Network

Network connections
RJ45 (2x)
Ethernet controller brand
Intel
Ethernet controller
Intel I210-AT
Max. port speed
10 Gbit/s

Audio

Chip
Realtek ALC1220, Realtek ALC4050H
Audio channel
7.1 Channel
Audio Connections
Jack 3.5mm (5x), Optical TOSLINK (1x)

Data storage

RAID configuration
0, 1, 10, 5

Internal interfaces

Internal connection options
S-ATA III (4x)
Expansion slot
PCI Express x16 (6x)
Number of fan connector
9

Further connections

USB ports
USB-A, USB-C
Exact USB ports
USB-A 3.2 Gen 1 (2x)

Power supply

Power connectors
24-pin ATX, 8-pin ATX 12V

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
HD Audio (8-channel)

Product dimensions

Length
330.20 mm
Width
304.80 mm
Height
330.20 mm
Weight
900 g

Package dimensions

Length
46.10 cm
Width
37.20 cm
Height
9.10 cm
Weight
2.02 kg
