Sunricher Radio dimming actuator ZigBee 3.0 400 W RC Single Line

Philips Hue compatible UP Dimmer

• Input voltage: 100 - 240 V, single line connection possible (no neutral wire required)
• 400 W high voltage halogen, 200 W LED, low voltage halogen
• Minimum brightness adjustable
• Button input 8 - 240 V
• Supports Touchlink, Philips Hue, and Amazon Alexa
• 30 remote controls can be paired

The SR-ZG9101SAC-HP is a ZigBee 3.0 phase-cut dimmer. It is compatible with all universal ZigBee 3.0 controllers and gateways.

Philips Hue and Alexa compatible

The dimmer from Sunricher is fully compatible with Philips Hue and Amazon Alexa. It is recognized by the Hue Bridge and displayed as a light in the app. This allows it to be managed in the app just like any other Hue device. It can also be directly connected via Touchlink to the Hue Dimmer Switch or another ZigBee 3.0 remote control.

Connection

The single line dimmer can be operated with or without a neutral wire. This makes it ideal for installation behind switches where no neutral wire is available. If a minimum load of 3-7 W is not met, a bypass device is required or the neutral wire must be connected.
