Stahl Mushroom stay-put button Oe/S emergency stop 130679Switching contacts

Stahl Mushroom Emergency Stop Button 8040/1180X-10L07SA05

Manufacturer: Stahl
Designation: Mushroom Emergency Stop Button Oe/S
Type: 8040/1180X-10L07SA05
Number of command points: 1
Button shape: high
Button color: red
Lens shape: round
Suitable for lighting: no
Latch switching function: yes
Push-button: no
Number of contacts as normally closed: 1
Number of contacts as normally open: 1
Electrical connection type: screw connection
Protection class (IP): IP66

Stahl Mushroom Emergency Stop Button 8040/1180X-10L07SA05: additional details
With the command device system of the 8040 series, you can organize command devices clearly. The three combinable sizes and modular design offer flexibility. There is a standard version and custom variants available. The contact elements 8208 monitor the systems for wire breakage and short circuits.
