Product details
The STAHL 8008/2-102 control switch is an explosion-proof device designed for use in hazardous environments. With a rated operating voltage of up to 690 V and a maximum operating current of 16 A, this switch provides reliable control in demanding applications. The epoxy resin housing ensures high resistance to environmental influences, while the silver-nickel contacts offer excellent conductivity. The switch is suitable for use in Zones 1 and 2 and meets the requirements for gas explosion protection according to II 2 G Ex db eb IIC T6. With a wide temperature range of -50 °C to +60 °C, it is versatile and suitable for various industrial applications.
- Explosion-proof for Zones 1 and 2
- High-quality materials: epoxy resin housing and silver-nickel contacts
- Operating voltage up to 690 V and operating current up to 16 A
- Temperature resistant from -50 °C to +60 °C.
Colour | Black |
Switch + button type | Load switch |
Mounting type | Built-in installation |
Item number | 32065121 |
Manufacturer | Stahl |
Category | Buttons + Switches |
Manufacturer no. | 128250 |
Release date | 17.10.2022 |
Colour | Black |
Material group | Plastic |
Material | Epoxy resin, Silver-nickel |
Switch + button type | Load switch |
Number of actuation levels | 2x |
Mounting type | Built-in installation |
Number of poles | 4x |
Nominal voltage | 690 V |
Nominal current | 16 A |
Protection type (IP code) | IP00 |
Country of origin | Germany |
CO₂ emissions | 95.84 kg |
Climate contribution | CHF 2.28 |
Smart home | Not compatible |
Items per sales unit | 1 pcs. |
