Siemens SIEM 6GK5204-2BC00-2AF2 SCALANCE XF204-2 Switch, 4x10/100 MBit/s

Siemens Dig.Industr. Scalance XF204-2 6GK5204-2BC00-2AF2

Manufacturer: Siemens Dig.Industr.
Designation: Scalance XF204-2
Type: 6GK5204-2BC00-2AF2
Ethernet: yes
Number of 10/100 Mbps RJ45 ports: 4
Number of 100 Mbps ST ports: 2
Number of other ports: 2
Mounting type: DIN rail
Layer 2: yes
Layer 3: no
Manageable: yes
Protection class (IP): IP20
Height: 125 mm
Width: 75 mm
Depth: 73 mm

Additional details:
SCALANCE XF204-2, flat, managed IE switch, 4x 10/100 Mbit/s RJ45 ports, 2x 100 Mbit/s FO ports, fault reporting contact with set button, redundant power supply, PROFINET IO Device, network management, integrated redundancy manager, including electronic manual on CD-ROM, C-PLUG optional.

The SCALANCE XF204-2 is a managed Layer 2 flat switch with 4x 10/100 Mbit/s RJ45 and 2x 100 Mbit/s multimode ST/BFOC for cabinet installation in SIMATIC ET 200S design.

Suitable for many tasks: The SCALANCE XF204-2 offers a wide variety of high-performance Ethernet switches in different variants – from Gigabit switches to robust switches for the requirements of process and discrete automation. The powerful Gigabit switches SCALANCE XF204-2 are designed for demanding networks in industrial environments. Thanks to its powerful hardware and advanced features, you benefit from a reliable and scalable network infrastructure for any application. Easily and reliably solve many industrial applications.

EAN: 4019169194013.
